Flat countersink Flat countersink

P M K S N 180° P M K S N 180°

Cat. no. HSS Factory Cat. no. HSS Factory

	N/mm2 N/mm2	HB	N/mm2	standard N/mm2	N/mm2 N/mm2	HB	standard N/mm2 N/mm2
			Copper,				Copper,
			brass,				brass,
112300 < 850	< 750	< 250 Titanium		Plastics 112350 < 850	< 750	< 250 Titanium	Plastics
			Alu <	UNI			UNI Alu <
				MK 600			MK 600
		vc = m/min.		shank		vc = m/min.	shank
112300 18-28	4-10	8-20	4-10 10-80	10-80 112350 18-28	4-10	8-20	11 10-80 4-10 10-80
Design:				Design:
- with MT shank and rigid pilot pin				- with MT shank and rigid pilot pin
- quality level fine for through hole				- grade medium for through hole
- for countersinks to DIN 74				- for countersinks to DIN 74
(sheet 2 form H, J + K)				(sheet 2 form H, J + K)

(z9) (e8) (z9) (e8)

112300 PRECITOOL, HSS, through hole fine 112350 PRECITOOL, HSS, through hole medium

for screws	112300	d1 mm	d3 mm	l1 mm	MT	f mm/U
M10		18	10�5	150	2	0�080 - 0�200
M12		20	13�0	150	2	0�090 - 0�240
M14		24	15�0	160	2	0�090 - 0�240
M16		26	17�0	190	3	0�120 - 0�300
M18		30	19�0	190	3	0�120 - 0�300
M20		33	21�0	190	3	0�120 - 0�300
M24		40	25�0	205	3	0�120 - 0�300

for screws	112350	d1 mm	d3 mm	l1 mm	MT	f mm/U
M10		18	11�0	150	2	0�080 - 0�200
M12		20	13�5	150	2	0�090 - 0�240
M14		24	15�5	160	2	0�090 - 0�240
M16		26	17�5	190	3	0�120 - 0�300
M18		30	20�0	190	3	0�120 - 0�300
M20		33	22�0	190	3	0�120 - 0�300
M24		40	26�0	205	3	0�120 - 0�300

Flat countersink set Piloted counterbore

HSS combi system

Design: Design:

112000: Set of counterbores 111000			DIN	- holder for all sizes
	HSS		373
112050: Depending on assortment the set includes				- within one size range all countersinks can be combined with all guide pins
		coated
	counterbores from 111050 or 111060			- the range from 5 mm to 85 mm diameter is covered in four sizes
112100: Set of counterbores 111100	180°			- holders with Weldon shank are as a standard with internal coolant supply
		Straight
Delivery:		shank		Note:

In plastic case. Countersinks size 2 can be used, too (from Ø 16.0 mm).

cylindrical

Weldon

MT2

112001 GFS, holder

Size	112001	Shankx	Counterborex from - to mm
01/10		10 mm	5�0 - 16�0
0/10		10 mm	7�0 - 24�0
0/MK1		MT 1	7�0 - 24�0
1/12		12 mm	10�0 - 38�0
1/MK2		MT 2	10�0 - 38�0
1/20		Weldon 20	10�0 - 38�0
2/MK2		MT 2	16�0 - 58�0
2/MK3		MT 3	16�0 - 58�0
2/25		Weldon 25	16�0 - 58�0
2/MK4		MT 4	60�0 - 85�0
2/MK5		MT 5	60�0 - 85�0
2/32		Weldon 32	60�0 - 85�0

Size	112000	112050	112100	1 countersink each M3/M4/M5/M6/M8/M10
7K				HSS in case M3-M10
7K/TIN	—		—	HSS/TiN in case M3 - M10
