Circle cutter
For metal machining the cutters work in draw cut, i.e. these cutters are generally clamped into an
inclined holder. Straight MK
shank shank
Use: Cutting depths: Sheet steel (max. 850 N/mm²) 5 mm. Sheet steel above 5 mm only with circle cutter 00A in conjunction with tool holder 108070. With holder for additional blade 108050-108060 straight blades can be mounted for "non- 10 drawing" cut. This allows the machining of the following materials: Soft plastics, plastic generally, rubber, leather, sealing material, acrylic glass up to 5 mm thickness. Hard plastics, polyamides, laminates up to 20 mm.
Delivery: Incl. one blade for steel machining.
108000 PRECITOOL, parallel and MT shank
Area Drill Ø Shank Ø/MT
Type 108000
| mm | mm | mm | ||
| LILIPUT | | 18- 80 | 5 | 10 |
| 00/12 | | 30-200 | 6 | 12 |
Liliput
| 00/MK2 | | 30-200 | 6 | MK2 |
| 00/MK3 | | 30-200 | 6 | MK3 |
| 00A/MK3 | | 30-400 | 8 | MK3 |
| 00 A/MK4 | | 30-400 | 8 | MK4 |
Accessories for circle cutters
For circle cutter 108000.
108050 PRECITOOL, steel support for straight cut metal
108060 PRECITOOL, steel support for straight cut plastic
108070 PRECITOOL, steel support for drawing cut
| Type | 108050 | 108060 | 108070 |
| 00A | | | |
| 00 | | | — |
Accessories for circle cutters
For circle cutter 108000 HSS-Co Carbide
108100-108240: PU = 5 pieces tipped
108250: PU = 2 pieces Spares for left-hand cut and TiN coated blades available on request.
108100 PRECITOOL, spare blade, HSS-Co, inclined, for sheet material up to 5 mm
108140 PRECITOOL, spare blade, carbide-tipped, for sheet metal up to 5 mm
108150 PRECITOOL, spare blade, HSS-Co inclined, left, for sheets up to 5 mm
108180 PRECITOOL, spare blade, HSS-Co for rubber and leather up to 10 mm
108200 PRECITOOL, spare blade, HSS-Co for plastics 2 - 30 mm
108240 PRECITOOL, spare blade, carbide-tipped for plastics 2 - 30 mm
108250 PRECITOOL, spare blade, HSS-Co, extra wide for thick sheets 2 - 12 mm (Ø <150 mm)
| Size | 108100 | 108140 | 108150 | 108180 | 108200 | 108240 | 108250 | Application | |
| 00-00A | | | | | | | | only for size 00A and combined with holder 108070, for sheets 2 to 12 mm and up to 150 mm x | |
| LILIPUT | | | | | | | — | for thin sheets up to 5 mm |
