Spring clamp Design: - movable contact surfaces for optimum contour adaptation - light and handy design, ergonomic handles - maximum stability 587312 Clippix XC Clamping rangemm 587312 Reachmm Weightkg 25  30 0.02 35  37 0.05 50  50 0.12 75  70 0.18 All-steel screw clamp Design: - heavy-duty clamp for heavy and heaviest stress - the optimised profile guarantees 20 % increased clamping power - fixed jaw and pressure plate made of one piece - sliding jaw in U-shape forged of tempered steel - movable, interchangeable special pressure plate with sintered steel insert pivotable up to 35° - for max. clamping pressure up to 12,000 N (equivalent to 40 Nm torque at 150 mm span width) Use: For steelwork, shipbuilding, engineering and vehicle construction Special pressure pad 587500 heavy version Clamping rangemm 587500 Reachmm Rail cross sectionmm Weightkg Clamping rangemm 587500 Reachmm Rail cross sectionmm Weightkg 250  140 34 × 13 2.5 800  140 34 × 13 4.4 300  140 34 × 13 2.9 1000  140 34 × 13 4.9 500  140 34 × 13 3.4 1500 + 140 34 × 13 6.5 All-steel U-clamp Design: - stationary jaw annealed and extremely torsion-resistant - heat-resistant, movable special pressure plate (up to 35°) - sliding bar made of die-forged Q & T steel - suitable for step-over clamping without supplements, in particular of T or double-T profiles - clamping force up to 12,000 N (tightening torque 40 Nm) Use: For steelwork, shipbuilding, engineering and vehicle construction 587510 heavy version Clamping rangemm 587510 Reachmm Rail cross sectionmm Weight kg 300  140 30 × 15 3.75 58 All-steel screw clamp Steel bar clamp Design: - like 587500, albeit with larger rail profile, thus suited for heaviest tasks - for max. clamping pressure up to 22,000 N (equivalent to 80 Nm torque at 150 mm span width) 587550 extra heavy-duty version Clamping rangemm 587550 Reachmm Rail cross sectionmm Weightkg Clamping rangemm 587550 Reachmm Rail cross sectionmm Weightkg 300  175 40 × 20 5.2 600  175 40 × 20 6.8 400  175 40 × 20 5.7 1000  175 40 × 20 8.8 500  175 40 × 20 6.4 — — — — — www.precitool.de 58/1135 Shears / Clamping Tools
