Spare pressure screw for sheet metal hole punch 586040 Spare standard pressure screw 586045 Spare ball bearing pressure screw Screw sizemm 586040 586045 for sheet metal hole punch sizemm M6×30  — 12.7 M6×40 —  12.7 586040 M8×1×35  — 15.2 M8×1×40 —  15.2 M10×1×45  — 16.0 - 25.0 M10×1×55   28.3 - 38.0 / 16.0 - 38.0 586045 M12×1,5×70   40.0 - 50.0 M16×1,5×80   54.0 - 60.0 M20×1,5×80   70.0 M20×1,5×90   70.0 - 80.0 Manual hydraulic punch Design: - operation pressure 600 bar - 360° rotatable and swivellable - ideal for hard-to-reach spaces - for punches up to 63.5 mm x - for box punches up to 36 x 62 mm - fitting for all manufactures Delivery: In steel box 586100 for punches up to 63.5 mm Type 586100 Contents 1  Punch complete in steel sheet case, 4 traction screws 8, 10, 12 and 16 mm,for round hole punches x 14 - 63.5 mm, 4 flat washers Hydraulic traction bolt Design: - with thread 3/4 - 16 UNF - fitting for hydraulic punch (586100) 586180 for hydraulic punch Nominal sizemm 586180 Thread x × lead × lengthmm 8    M8 × 1.0 ×   88 10  M10 × 1.0 ×   88 12  M12 × 1.5 × 103 16  M16 × 1.5 × 113 58 Deep jaw bar clamp Design: - sliding and fixed arm in sturdy double-T form made of malleable iron - 2-fold fluted hollow profile bar of steel - trapezoid thread spindle of steel - burnished, with movable pressure plate and red lacquered wooden handle 587102 Deep jaw bar clamp Chucking width/throatmm 587102 Rail cross sectionmm Chucking width/throatmm 587102 Rail cross sectionmm 400/200  35 × 11 400/300  45 × 12 600/200  35 × 11 600/300  45 × 12 400/250  40 × 11 800/300  45 × 12 600/250  40 × 11 800/400  45 × 12 58/1132 www.precitool.de Shears / Clamping Tools
