Carbide Micrograin Carbide End Mills List 412, 414 SPEEDFEED CARBIDEP1105-1108TiAINTiCN BR 30˚ 2 or 4 Flute, Metric Sizes, Stub Length Milling Diameter Tolerance 1≤D≤12 +0 / -0.05mm 412 414 EDP Number Mill Overall Length Shank List 412 (2 Flute) List 414 (4 Flute) Diameter Length of Cut Diameter Bright Bright TiAlN D L Lc d 412-0394 414-0394 414-039411 1.0 39 2 3 412-0591 414-0591 – 1.5 39 3 3 412-0787 414-0787 – 2.0 39 4 3 412-0984 414-0984 – 2.5 39 5 3 412-1181 414-1181 – 3.0 39 6 3 412-1378 414-1378 – 3.5 51 7 4 412-1575 414-1575 – 4.0 51 8 4 412-1772 414-1772 – 4.5 51 9 5 412-1968 414-1968 414-196811 5.0 51 10 5 412-2362 414-2362 – 6.0 51 12 6 412-2756 414-2756 – 7.0 51 12 8 412-3150 414-3150 – 8.0 51 12 8 412-3543 414-3543 – 9.0 51 14 10 412-3937 414-3937 – 10.0 51 14 10 412-4331 414-4331 – 11.0 64 16 11 412-4724 414-4724 – 12.0 64 16 12 Packed: 1 pc. EDP’s listed above are stocked standard, other coatings available upon request. Specify treatment at time of order. Work Material P M K N S H Chart Carbon Steels Alloyappliesto all listLownumbers1010above1018Med.10351045High1065SteelsDie4140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC - good best WWW.OSGTOOL.COM Carbide Square & Corner Radius 879
