NEXUS Vanadium High Speed Steel and OSG’s Proprietary WD1 Nanotechnology Coating List 1150 (Continued) SPEEDFEED HSSEP324-325WD1STUB 40˚ NEXUS-GDS, Designed for a Wide Range of Materials EDP Diameter Flute Overall Shank PointLengthLengthDiameterAngle Number Fractional Size Wire Gage Letter Size mm Inch FL L d α 11561815 - - - 9.05 0.3563 8650918 - - - 9.18 0.3614 8650920 - - - 9.20 0.3622 8650924 - - - 9.24 0.3638 40 90 8650934 - - - 9.34 0.3677 10 8650936 - - - 9.36 0.3685 11563215 3/8 - - 9.53 0.3750 11564115 25/64 - - 9.92 0.39068651000---10.000.3937 93 11564715 - - - 10.20 0.4016 8651030 - - - 10.30 0.4055 431156501513/32--10.320.4062100 120º 8651040 - - - 10.40 0.4094 8651050 - - - 10.50 0.4134 11565915 27/64 - - 10.71 0.4219 8651100 -115668157/16 -- -- 11.00 0.433111.110.437547 104 12 11567715 29/64 - - 11.51 0.4531 11568415 - - - 11.85 0.4665 8651200 -11568815- -- -- 12.00 0.472412.100.476451 108 11569415 1/2 - - 12.70 0.5000 Packed: 1 pc. Available WD1 coating only. Work Material P M K N S H Carbon Steels AlloyList No.Low10101018Med.10351045HighSteelsDie10654140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC 1150 good best WWW.OSGTOOL.COM NEXUS 247
