140° ØD Ød CARBIDE Straight Drills List 200 SPEEDFEEDCARBIDEP315-316BR 0˚ Cutting Diameter Tolerance Size mm inch 1.18≤D≤12.7 +0 / -0.013 +0 / -0.0005 Four FacetPoint FL L (D≤1.5) EDP Diameter Flute Overall ShankLengthLengthDiameter Number FractionalSize Wire Gage Letter Size mm Inch FL L d 200-0465 - 56 - 1.18 0.0465 1.18 200-0469 3/64 - - 1.19 0.0469 3/64 200-0520 -200-0550- 5554 -- 1.32 0.05201.400.0550 13 38 1.321.40 200-0591 - - - 1.50 0.0591 1.50 200-0595 - 53 - 1.51 0.0595 1.51 200-0625 1/16 - - 1.59 0.0625 16 41 1/16 200-0635 - 52 - 1.61 0.0635 1.61 200-0670 - 51 - 1.70 0.0670 1.70 200-0700 -200-0730- 5049 -- 1.78 0.07001.850.0730 17 43 1.781.85 200-0760 - 48 - 1.93 0.0760 1.93 200-0781 5/64 - - 1.98 0.0781 5/64 200-0785 - 47 - 1.99 0.0785 1.99 200-0787 - - - 2.00 0.0787 2.00 200-0810 - 46 - 2.06 0.0810 2.06 200-0820 -200-0860- 4544 -- 2.08 0.08202.180.0860 19 44 2.082.18 200-0890 - 43 - 2.26 0.0890 2.26 200-0935 - 42 - 2.37 0.0935 2.37 200-0938 3/32 - - 2.38 0.0938 3/32 200-0960 - 41 - 2.44 0.0960 2.44 200-0980 - 40 - 2.49 0.0980 2.49 200-0984 - - - 2.50 0.0984 2.50 200-0995 -200-1015- 3938 -- 2.53 0.09952.580.1015 21 46 2.532.58 200-1040 - 37 - 2.64 0.1040 2.64 200-1065 - 36 - 2.71 0.1065 2.71 200-1094 7/64 - - 2.78 0.1094 7/64 200-1100 - 35 - 2.79 0.1100 2.79 200-1110 - 34 - 2.82 0.1110 2.82 200-1130 - 33 - 2.87 0.1130 2.87 200-1160 - 32 - 2.95 0.1160 22 48 2.95 200-1181 - - - 3.00 0.1181 3.00 200-1200 - 31 - 3.05 0.1200 3.05 200-1250 1/8 - - 3.18 0.1250 1/8 200-1285 - 30 - 3.26 0.1285 3.26 200-1360 -200-1378- 29- -- 3.45 0.13603.500.1378 24 49 3.453.50 200-1405 - 28 - 3.57 0.1405 3.57 Packed: 1 pc. EDP’s listed above are stocked standard, other coatings available upon request. Specify treatment at time of order: 05 = TiN, 08 = TiCN, 11 = TiAlN. Work Material P M K N S H Carbon Steels AlloyList No.Low10101018Med.10351045HighSteelsDie10654140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC 200 good best WWW.OSGTOOL.COM CARBIDE 207
