ØD ØD2 ® PXM Exchangeable Head End Mill List 78PXSM SPEEDFEED P1297 PXSM Exchangeable Heads (Inch & Metric) - Multiple Flute, Square & Corner Radius Accessories: p1292-1294 PXM Arbors: p1290-1291 r Lc L Head Corner Length Overall Flange EDP No. Type Designation Dia. D Radius No. of Cut LengthrofFlutesLcL Dia.D2 HelixAngleGrade (mm) (inch) (mm) (inch) (mm) (inch) (mm) (inch) (mm) (inch) 52302000 PXSM0500AC12-06R000 - 0.500 - 0.000 6 - 0.350 - 0.598 - 0.488 38° XP3225 52302001 PXSM0500AC12-06R015 - 0.500 - 0.015 6 - 0.350 - 0.598 - 0.488 38° XP3225 52302002 PXSM0500AC12-06R030 - 0.500 - 0.030 6 - 0.350 - 0.598 - 0.488 38° XP3225 52302003 PXSM0500AC12-06R060 - 0.500 - 0.060 6 - 0.350 - 0.598 - 0.488 38° XP3225 52302004 PXSM0500AC12-06R090 - 0.500 - 0.090 6 - 0.350 - 0.598 - 0.488 38° XP3225 52302005 PXSM0625AC16-06R000 - 0.625 - 0.000 6 - 0.438 - 0.732 - 0.613 38° XP3225 52302006 PXSM0625AC16-06R030 - 0.625 - 0.030 6 - 0.438 - 0.732 - 0.613 38° XP3225 52302007 PXSM0625AC16-06R060 - 0.625 - 0.060 6 - 0.438 - 0.732 - 0.613 38° XP3225 52302008 PXSM0625AC16-06R090 - 0.625 - 0.090 6 - 0.438 - 0.732 - 0.613 38° XP3225 52302009 PXSM0625AC16-06R120 - 0.625 - 0.120 6 - 0.438 - 0.732 - 0.613 38° XP3225 52302010 PXSM0625AC16-08R000 - 0.625 - 0.000 8 - 0.438 - 0.732 - 0.613 42° XP3225 52302011 PXSM0625AC16-08R030 - 0.625 - 0.030 8 - 0.438 - 0.732 - 0.613 42° XP3225 52302012 PXSM0625AC16-08R060 - 0.625 - 0.060 8 - 0.438 - 0.732 - 0.613 42° XP3225 52302013 PXSM0625AC16-08R090 - 0.625 - 0.090 8 - 0.438 - 0.732 - 0.613 42° XP3225 52302014 PXSM0625AC16-08R120 - 0.625 - 0.120 8 - 0.438 - 0.732 - 0.613 42° XP3225 52302015 PXSM0750AC20-10R000 - 0.750 - 0.000 10 - 0.525 - 0.807 - 0.736 42° XP3225 52302016 PXSM0750AC20-10R030 - 0.750 - 0.030 10 - 0.525 - 0.807 - 0.736 42° XP3225 52302017 PXSM0750AC20-10R060 - 0.750 - 0.060 10 - 0.525 - 0.807 - 0.736 42° XP3225 52302018 PXSM0750AC20-10R090 - 0.750 - 0.090 10 - 0.525 - 0.807 - 0.736 42° XP3225 52302019 PXSM0750AC20-10R120 - 0.750 - 0.120 10 - 0.525 - 0.807 - 0.736 42° XP3225 52302020 PXSM1000AC25-10R000 - 1.000 - 0.000 10 - 0.700 - 1.098 - 0.960 42° XP3225 52302021 PXSM1000AC25-10R030 - 1.000 - 0.030 10 - 0.700 - 1.098 - 0.960 42° XP3225 52302022 PXSM1000AC25-10R060 - 1.000 - 0.060 10 - 0.700 - 1.098 - 0.960 42° XP3225 52302023 PXSM1000AC25-10R090 - 1.000 - 0.090 10 - 0.700 - 1.098 - 0.960 42° XP3225 52302024 PXSM1000AC25-10R120 - 1.000 - 0.120 10 - 0.700 - 1.098 - 0.960 42° XP3225 7830104 PXSM PXSM120C12-06R000 12 - 0 - 6 8.4 - 14.4 - 11.7 - 38° XP3225 7830105 PXSM120C12-06R005 12 - 0.5 - 6 8.4 - 14.4 - 11.7 - 38° XP3225 7830106 PXSM120C12-06R010 12 - 1 - 6 8.4 - 14.4 - 11.7 - 38° XP3225 7830107 PXSM120C12-06R020 12 - 2 - 6 8.4 - 14.4 - 11.7 - 38° XP3225 7830108 PXSM120C12-06R030 12 - 3 - 6 8.4 - 14.4 - 11.7 - 38° XP3225 7830109 PXSM160C16-06R000 16 - 0 - 6 11.2 - 18.7 - 15.7 - 38° XP3225 7830110 PXSM160C16-06R005 16 - 0.5 - 6 11.2 - 18.7 - 15.7 - 38° XP3225 7830111 PXSM160C16-06R010 16 - 1 - 6 11.2 - 18.7 - 15.7 - 38° XP3225 7830112 PXSM160C16-06R015 16 - 1.5 - 6 11.2 - 18.7 - 15.7 - 38° XP3225 7830113 PXSM160C16-06R020 16 - 2 - 6 11.2 - 18.7 - 15.7 - 38° XP3225 7830114 PXSM160C16-06R030 16 - 3 - 6 11.2 - 18.7 - 15.7 - 38° XP3225 7830115 PXSM160C16-08R000 16 - 0 - 8 11.2 - 18.7 - 15.7 - 42° XP3225 7830116 PXSM160C16-08R005 16 - 0.5 - 8 11.2 - 18.7 - 15.7 - 42° XP3225 7830117 PXSM160C16-08R010 16 - 1 - 8 11.2 - 18.7 - 15.7 - 42° XP3225 7830118 PXSM160C16-08R015 16 - 1.5 - 8 11.2 - 18.7 - 15.7 - 42° XP3225 7830119 PXSM160C16-08R020 16 - 2 - 8 11.2 - 18.7 - 15.7 - 42° XP3225 7830120 PXSM160C16-08R030 16 - 3 - 8 11.2 - 18.7 - 15.7 - 42° XP3225 7830121 PXSM200C20-10R000 20 - 0 - 10 14 - 21.5 - 19.6 - 42° XP3225 7830122 PXSM200C20-10R005 20 - 0.5 - 10 14 - 21.5 - 19.6 - 42° XP3225 7830123 PXSM200C20-10R010 20 - 1 - 10 14 - 21.5 - 19.6 - 42° XP3225 7830124 PXSM200C20-10R020 20 - 2 - 10 14 - 21.5 - 19.6 - 42° XP3225 7830125 PXSM200C20-10R030 20 - 3 - 10 14 - 21.5 - 19.6 - 42° XP3225 7830126 PXSM250C25-10R000 25 - 0 - 10 17.5 - 27.5 - 24 - 42° XP3225 7830127 PXSM250C25-10R010 25 - 1 - 10 17.5 - 27.5 - 24 - 42° XP3225 7830128 PXSM250C25-10R020 25 - 2 - 10 17.5 - 27.5 - 24 - 42° XP3225 7830129 PXSM250C25-10R030 25 - 3 - 10 17.5 - 27.5 - 24 - 42° XP3225 Packed: 1 pc. WWW.OSGTOOL.COM OSG PHOENIX® PXM 1285
