ØD Ød ØD Ød ® PSEL Rough Milling Cutter List 78029 SPEEDFEED P1212 PSEL SS (Metric) Recommended Materials: p1213 Accessories & Inserts: p1210-1211 EDP No. BodyTypeTeethType Designation Type ToolDia. (mm)D No. of Teeth No. of Inserts per Tooth Total No. of Inserts Length of Cut (mm) Lc ShankDia.(mm)dOverallLength(mm)LNeckLength(mm)L1ApplicableInsert 7802900 PSEL11R025SS25-2-27 1 25 2 3 6 27.0 25 125 50 7802901 PSEL11R032SS32-2-37 1 32 2 4 8 37.0 32 140 60 78029027802903Cylindrical Shank Normal PSEL11R032SS32-3-45PSEL11R040SS42-3-37117802904PSEL11R040SS42-4-45132404033454515 45.5 32 1401237.0421402045.54214060ZD_T11…6060 78029057802906 PSEL15R040SS42-2-38 1 40 2PSEL15R050SS42-3-502503346 38.0 42 1401250.542144 6064 ZDKT15… Packed: 1 pc. Note: When using an insert with a corner radius of R2 or greater, the corner of the cutter body must be corrected. The body corner radius should equal insert radius minus one (example: if insert radius is R3, body radius should be R2). This item is stocked overseas. Please contact OSG for availability and delivery. Type 1 Type 2 Lc Lc l1 L l1 L With coolant hole. With coolant hole. 1208 OSG PHOENIX® PSEL WWW.OSGTOOL.COM
