SC
OSAWA NORM INFO
TYPHOON TA-HTA-4HTA
TYPHOON PU-HPU
TYPHOON SUH
TYPHOON ALH
| Always Per l’uso Tragen Toujour Para usa При ра | wear gogg delle lim Sie immer s porter le r las limas боте с бор | les when u e rotative è die Schutz s lunettes rotativas e фрезами | sing the ro obbligato brille wenn de securité s obligato всегда исп | tary burrs rio indoss Sie die Fr en utilisan rio usar ga ользуйте | are occhiali p äser benutz t les limes ro fas de prote защитные о | rotettivi en tatives cción чки | M | MPC | MNF | |||
| D | d (3) | d (6) | l | L | ANGLE | PACKAGING | EDP No. | Stock | EDP No. | Stock | EDP No. | Stock |
| 2.5 | 3 | 11 | 38 | 5 | SC41M | h | SC41MPC | h | ||||
| 3.0 | 3 | 14 | 38 | 5 | SC42M | h | SC42MPC | h | ||||
| 3.0 | 6 | 12 | 50 | 5 | SC11M | h | SC11MPC | f | ||||
| 4.0 | 6 | 13 | 50 | 5 | SC13M | h | SC13MPC | f | ||||
| 5.0 | 3 | 12.7 | 38 | 5 | SC53M | h | SC53MPC | h | ||||
| 5.0 | 6 | 16 | 50 | 5 | SC14M | h | SC14MPC | f | ||||
| 6.0 | 6 | 18 | 50 | 5 | SC1M | h | SC1MPC | f | SC1MNF | f | ||
| 6.3 | 3 | 12.7 | 45 | 5 | SC51M | h | SC51MPC | h | ||||
| 8.0 | 6 | 19 | 63 | 5 | SC2M | h | SC2MPC | f | ||||
| 9.5 | 6 | 19 | 63 | 5 | SC3M | h | SC3MPC | f | SC3MNF | f | ||
| 11.0 | 6 | 25 | 70 | 5 | SC4M | h | SC4MPC | f | ||||
| 12.7 | 6 | 25 | 70 | 5 | SC5M | h | SC5MPC | f | SC5MNF | f | ||
| 16.0 | 6 | 25 | 70 | 5 | SC6M | h | SC6MPC | f | SC6MNF | f | ||
| 19.0 | 6 | 25 | 70 | 5 | SC7M | f | SC7MPC | f | SC7MNF | f | ||
| 25.0 | 6 | 25 | 70 | 5 | SC9M | f | SC9MPC | f |
