MEX - 30÷55HRC - Corner radius CUTTING PARAMETERS INFO MEXLN2R TA-THYTPAH-4OHOTNA Material Group P2 P3 P4 K1 K2 P4 P5 K3 P6 K4 H1 H4 H5 ISO 513 Hardness/Rm < 1000 N/mm² < 35 HRC 35 - 45 HRC 45 - 55 HRC TYPPHUO-HOPNU ap x ae ap x D ap x D ap x D ap x D Vc (m/min) 70-110 50-90 30-70 20-40 TYPHOSOUNH D l1 ap n fz Vf n fz Vf n fz Vf n fz Vf (mm) (mm) (mm) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) (rpm) (mm/z) (mm/min) ≤ 6D 0.09 15900 0.028 890 12400 0.025 620 8800 0.022 395 5300 0.020 210 ≤ 8D 0.08 14300 0.025 720 11100 0.023 500 8000 0.020 325 4800 0.018 170 TYPHOAOLNH 1.8 ≤ 10D 0.06 12700 0.022 570 9900 0.020 400 7100 0.018 255 4200 0.016 130 ≤ 12D 0.05 11100 0.020 440 8700 0.018 310 6200 0.016 195 3700 0.014 100 ≤ 15D 0.04 9600 0.017 320 7400 0.015 220 5300 0.013 140 3200 0.012 75 TYPHOHORNC > 15D 0.03 8000 0.014 220 6200 0.013 160 4400 0.011 100 2700 0.010 55 ≤ 6D 0.10 14300 0.030 860 11100 0.027 600 8000 0.024 385 4800 0.021 200 ≤ 8D 0.09 12900 0.027 700 10000 0.024 490 7200 0.022 310 4300 0.019 165 TSYUPHHOMOINNI 2 ≤ 10D 0.07 11500 0.024 550 8900 0.022 380 6400 0.019 245 3800 0.017 130 ≤ 12D 0.06 10000 0.021 420 7800 0.019 290 5600 0.017 190 3300 0.015 95 ≤ 15D 0.05 8600 0.018 310 6700 0.016 220 4800 0.014 140 2900 0.013 75 SQUARE RIB > 15D 0.03 8600 0.018 310 6700 0.016 220 4800 0.014 140 2900 0.013 75 TYPHOOHNL ≤ 6D 0.13 11500 0.035 810 8900 0.032 560 6400 0.028 360 3800 0.025 185 ≤ 8D 0.11 10300 0.032 650 8000 0.028 450 5700 0.025 285 3400 0.022 150 2.5 ≤ 10D 0.09 9200 0.028 520 7100 0.025 360 5100 0.022 230 3100 0.020 120 C-SD-TA ≤ 12D 0.07 8000 0.025 390 6200 0.022 270 4500 0.020 175 2700 0.017 95 ≤ 15D 0.06 6900 0.021 290 5400 0.019 200 3800 0.017 130 2300 0.015 70 > 15D 0.04 6900 0.021 290 5400 0.019 200 3800 0.017 130 2300 0.015 70 ≤ 6D 0.15 9600 0.040 770 7400 0.036 530 5300 0.032 340 3200 0.028 180 LFTA ≤ 8D 0.13 8600 0.036 620 6700 0.032 430 4800 0.029 275 2900 0.025 145 3 ≤ 10D 0.11 7600 0.032 490 5900 0.029 340 4200 0.026 215 2500 0.022 110 ≤ 12D 0.08 6700 0.028 380 5200 0.025 260 3700 0.022 165 2200 0.020 85 SUTA ≤ 15D 0.07 5700 0.024 270 4500 0.022 190 3200 0.019 125 1900 0.017 65 > 15D 0.05 5700 0.024 270 4500 0.022 190 3200 0.019 125 1900 0.017 65 ≤ 6D 0.20 7200 0.050 720 5600 0.045 500 4000 0.040 320 2400 0.035 170 HSS-HDSSR/ILCLOS ≤ 8D 0.17 6400 0.045 580 5000 0.041 410 3600 0.036 260 2100 0.032 130 4 ≤ 10D 0.14 5700 0.040 460 4500 0.036 320 3200 0.032 205 1900 0.028 105 ≤ 12D 0.11 5000 0.035 350 3900 0.032 250 2800 0.028 155 1700 0.025 85 ≤ 15D 0.09 4300 0.030 260 3300 0.027 180 2400 0.024 115 1400 0.021 60 G2 > 15D 0.06 4300 0.030 260 3300 0.027 180 2400 0.024 115 1400 0.021 60 MDTA HF VH/UP MEF ALU MEX UH HSSE/NCDO-MHISLSLPS CARBIDE BURRS 552
