• Primary P • • Secondary M • K • N • S • H Kenloc™ Inserts KCU10B TNMG Insert • Negative • RP ISO ANSI D L10 Rε Catalog Number Catalog Number mm in mm in mm in TNMG160408RP TNMG332RP 9,53 3/8 16,50 .650 0,8 1/32 • TNMG160412RP TNMG333RP 9,53 3/8 16,50 .650 1,2 3/64 • TNMG220408RP TNMG432RP 12,70 1/2 22,00 .866 0,8 1/32 • TNMG220412RP TNMG433RP 12,70 1/2 22,00 .866 1,2 3/64 • TNMG220432RP TNMG438RP 12,70 1/2 22,00 .866 3,2 1/8 • TNMG270612RP TNMG543RP 15,88 5/8 27,50 1.083 1,2 3/64 • TNMG330924RP TNMG666RP 19,05 3/4 33,00 1.299 2,4 3/32 • • Primary P • • Secondary M • K • N • S • H Kenloc™ Inserts KCU10B VNGG Insert • Negative • FS ISO ANSI D L10 Rε Catalog Number Catalog Number mm in mm in mm in VNGG160401FS VNGG3302FS 9,53 3/8 16,61 .654 0,1 .004 • VNGG160402FS VNGG3305FS 9,53 3/8 16,61 .654 0,2 .008 • VNGG160404FS VNGG331FS 9,53 3/8 16,61 .654 0,4 1/64 • VNGG160408FS VNGG332FS 9,53 3/8 16,61 .654 0,8 1/32 • • Primary P • • Secondary M • K • N • S • H Kenloc™ Inserts KCU10B VNGP Insert • Negative ISO ANSI D L10 Rε Catalog Number Catalog Number mm in mm in mm in VNGP160401 VNGP3302 9,53 3/8 16,61 .654 0,1 .004 • VNGP160402 VNGP3305 9,53 3/8 16,61 .654 0,2 .008 • VNGP160404 VNGP331 9,53 3/8 16,61 .654 0,4 1/64 • 17
