Цветные металлы Жаропрочные сплавы
- Перечень обрабатываемых материалов • Цветные металлы • N4 (продолжение)
- Перечень обрабатываемых материалов • Жаропрочные сплавы • S1
N4 S1
Сплавы на основе меди, латуни, цинка с обрабатываемостью материала в диапазоне 70–100 N4 Жаропрочные сплавы на основе железа S1 Предел прочности на разрыв RM (МПа)*: 500–1200 Твердость (HB): 160–260 (HRC): 25–48
Номер Название Номер Название
| AISI** | DIN | BTS | JIS | UNS | EN | AFNOR | UNI | SIS | SAE | ASTM | материала производителя | |
| – | S-CuNi 10 Fe | – | – | – | – | – | – | – | – | – | 2.0873 | – |
| – | CuNi 30 Mn 1 Fe | – | – | – | – | – | – | – | – | – | 2.0882 | – |
| – | SG-Cu Al 8 | – | – | – | – | – | – | – | – | – | 2.0921 | – |
| – | SG-CuAl 8 Ni 2 | – | – | – | – | – | – | – | – | – | 2.0922 | – |
| – | SG-CuAl 9 Ni5 Fe | – | – | – | – | – | – | – | – | – | 2.0927 | – |
| – | CuAl 10 Fe 3 Mn 2 | CA 103 | – | – | – | U-A 10 Fe | – | – | – | – | 2.0936 | – |
| – | SG-Cu Al 10 Fe | – | – | – | – | – | – | – | – | – | 2.0937 | – |
| C 63000 | CuAl 10 Ni 5 Fe 4 | Ca 104 | – | – | – | U-A 10 N | – | – | – | – | 2.0966 | – |
| B-148-52 | G-CuAl 10 Ni | – | – | – | – | – | – | – | – | – | 2.0975 | – |
| – | SG-Cu Sn | – | – | – | – | – | – | – | – | – | 2.1006 | – |
| – | SG-Cu Sn 6 | – | – | – | – | – | – | – | – | – | 2.1022 | – |
| C 90800 | G-CuSn 12 | Pb 2 | – | – | – | UE 12 P | – | – | – | – | 2.1052 | – |
| – | G-CuSn 12 Pb | – | – | – | – | – | – | – | – | – | 2.1061 | – |
| AISI** | | DIN | BTS | JIS | UNS | EN | AFNOR | | UNI | SIS | SAE | ASTM | материала | производителя | |
| – | | X 10 Cr 25 | – | – | – | – | | – | – | – | – | – | 1.3811 | | – |
| – | | D 1 a | – | – | – | – | | – | – | – | – | – | 1.3915 | | – |
| – | | D 3 | BD 3 | – | – | X 210 Cr 1 2 | Z 200 C 12 | | X 205 Cr 12 KU | – | – | – | 1.3916 | | – |
| – | | RNi 12 | – | – | – | – | | – | – | – | – | – | 1.3926 | | – |
| – | | RNi 8 | – | – | – | – | | – | – | – | – | – | 1.3927 | | – |
| – | GX 2 NiCoMoTi1 7 10 | | – | – | – | – | | – | – | – | – | – | 1.6351 | Maraging | |
| 6501, 6512, 6520 | X 2 NiCoMo 18 8 5 | | – | – | UNS K92890 | S162 | Z2NKD18.8 | | – | – | – | ASTM A646 | 1.6359 | ATI VascoMax® C-250 | |
| – | X 2 NiCoMo 18-8-5 | | – | – | K92890 | – | | – | – | – | – | – | 1.6359 | Maraging | |
| – | X 1 CrNiCoMo 13 8 5 | | – | – | – | – | | – | – | – | – | – | – | Maraging | |
| – | | Ni 36 | – | – | – | – | | – | – | – | – | – | 1.3910 | Magnifer 36 | |
| – | | Ni 46 | – | – | – | – | | – | – | – | – | – | 1.3920 | | – |
| – | X 2 CrNiCoMo 12 8 5 | | – | – | – | – | | – | – | – | – | – | 1.6980 | Maraging | |
| ASTM B463 | | – | – | – | UNS N08020 | – | | – | – | – | – | ASTM B463 | 2.4660 | | 20CB-3 |
| | | | | | | | | | | Номер | Название |
| AISI | DIN | BTS | JIS | UNS | EN | AFNOR | UNI | SIS | SAE | ASTM | материала | производителя |
| – | X 10 Cr 25 | – | – | – | – | – | – | – | – | – | 1.3811 | – |
| – | D 1 a | – | – | – | – | – | – | – | – | – | 1.3915 | – |
| – | D 3 | BD 3 | – | – | X 210 Cr 1 2 | Z 200 C 12 | X 205 Cr 12 KU | – | – | – | 1.3916 | – |
| – | RNi 12 | – | – | – | – | – | – | – | – | – | 1.3926 | – |
| – | RNi 8 | – | – | – | – | – | – | – | – | – | 1.3927 | – |
| – | GX 2 NiCoMoTi1 7 10 | – | – | – | – | – | – | – | – | – | 1.6351 | Maraging |
| 6501, 6512, 6520 | X 2 NiCoMo 18 8 5 | – | – | UNS K92890 | S162 | Z2NKD18.8 | – | – | – | ASTM A646 | 1.6359 | ATI VascoMax®C-250 |
| – | X 2 NiCoMo 18-8-5 | – | – | K92890 | – | – | – | – | – | – | 1.6359 | Maraging |
| – | X 1 CrNiCoMo 13 8 5 | – | – | – | – | – | – | – | – | – | – | Maraging |
| – | Ni 36 | – | – | – | – | – | – | – | – | – | 1.3910 | Magnifer 36 |
| – | Ni 46 | – | – | – | – | – | – | – | – | – | 1.3920 | – |
| – | X 2 CrNiCoMo 12 8 5 | – | – | – | – | – | – | – | – | – | 1.6980 | Maraging |
| ASTM B463 | – | – | – | UNS N08020 | – | – | – | – | – | ASTM B463 | 2.4660 | 20CB-3 |
| ASTM A666 | – | – | – | – | – | – | – | – | – | ASTM A666 | – | 6/21/09 |
| ASTM B753 | – | – | – | – | – | – | – | – | – | ASTM B753 | – | AL 4750 |
| S66286 | – | – | NAS 660 | UNS S66286 | – | – | A-286 | – | – | – | – | ATI A286™ |
| – | – | – | – | UNS K92810 | – | – | – | – | – | – | – | ATI VascoMax®C-200 |
| 6514 | – | – | – | UNS K93120 | – | – | – | – | – | – | – | ATI VascoMax®C-300 |
| – | – | – | – | – | – | – | – | – | – | – | – | ATI VascoMax®C-350 |
| – | – | – | – | – | – | – | – | – | – | – | – | ATI VascoMax®T-200 |
| 6518, 6519, 6591 | – | – | – | – | – | – | – | – | – | – | – | ATI VascoMax®T-250 |
| – | – | – | – | – | – | – | – | – | – | – | – | ATI VascoMax®T-300 |
| 5725 | – | – | – | – | – | Z3NCT25 | – | – | SAE 16-25-6 | – | – | Discaloy 16-25-6 |
| ASTM A638 | – | – | – | – | – | Z3NCT25 | – | – | Discaloy | ASTM A638 | – | Discaloy 24 |
| – | – | – | – | R30556 | – | – | – | – | – | – | – | Haynes®556 |
| 5768 | X 12 CrCoNi 21 20 | – | – | – | – | Z12CKNDWNb21.20.20 | – | – | – | – | – | Haynes 556 |
| ASTM F30 | – | – | – | – | – | – | – | – | Invar | ASTM F30 | – | Invar 42 |
| 5768 | – | – | – | UNS R30155 | – | Z12CNKDW20 | – | – | – | – | – | Multimet N-155 |
| – | – | – | – | – | – | – | – | – | – | – | – | Multimet N-156 |
| 5533 | X 40 CoCrNi 20 20 | – | – | – | – | Z42CKNDW | – | – | – | – | – | S 590 |
| – | X 2 NiCrAlTi 32 20 | – | – | – | – | – | – | – | – | – | – | Sanicro 30 |
| AlSl:665 | – | – | – | – | – | Z8NCTDA2613 | – | – | – | – | – | W-545 |
| – | CoCr 21 Mo 11 W | | – | – | | – | – | KC21W11ANbT | | – | – | – | | – | – | WI-52 |
| – | | – | – | – | | – | – | KC25N10W7Fe | | – | – | – | | – | – | X 45 |
| – | | – | – | – | | – | – | | – | – | – | J-1570 | | – | – | – |
| – | K13C20N126Fe15D7 | | – | – | R3003 и R3008 | | – | K13C20N126Fe15D7 | | – | – | – | ASTM F1058 | | – | – |
ПРИМЕЧАНИЕ. Пояснение см. на стр. Y217.
| AISI | DIN | BTS | JIS | UNS | EN | AFNOR | UNI | SIS | SAE | ASTM | Номер материала | Название производителя |
| – | CoCr 26 Ni 9 Mo | – | – | – | – | – | – | – | – | – | 2.4681 | – |
| – | CoCr 25 NiW | – | – | – | – | KC25WN | – | – | – | ASTM A567 | 2.4682 | Stellite®31 (X40) |
| – | CoCr 22 NiW | – | – | – | – | – | – | – | – | – | 2.4683 | – |
| – | CoCr 28 Mo | – | – | – | – | KC27D5NFe | – | – | – | ASTM F-75 | 2.4691 | HS 21 |
| – | CoCr 20 Ni 15 Mo | – | – | – | – | – | – | – | – | – | 2.4711 | – |
| – | CoCr 29 Mo | – | – | – | – | – | – | – | – | – | 2.4723 | – |
| – | CoCr 33 W | – | – | – | – | – | – | – | – | – | 2.4775 | – |
| – | CoCr 28 | – | – | – | – | – | – | – | – | – | 2.4778 | – |
| – | CoCr 28 Nb | – | – | – | – | – | – | – | – | – | 2.4779 | – |
| – | – | – | – | – | – | – | – | – | – | ASTM F90 | 2.4964 | F 90 |
| – | – | – | – | R30605 | – | KC20WN | – | – | – | – | 2.4964 | Haynes 25 |
| – | CoCr 20 W 15 Ni | HR 240 | – | R30605 | – | KC20WN | – | – | – | 5759 | 2.4964 | L 605 |
| – | CoCr 20 W 15 Ni | – | – | L605,литье | – | KC20WN | – | – | – | 5759 | 2.4964 | Stellite 25 |
| AMS 5399 | NiCr 19 Co 11 MoTi | – | – | – | – | NC 19 KDT | – | – | – | – | 2.4973 | – |
| – | CoCr 20 Ni 20 W | – | – | – | – | – | – | – | – | 5534 | 2.4979 | S 816 |
| – | CoCr20NiW | – | – | – | – | – | – | – | – | – | 2.4989 | – |
| – | – | – | – | R31537иR31538 | – | CoCr28Mo | – | – | – | ASTM F1537 | – | F 1537 |
| – | – | – | – | – | – | – | – | – | – | ASTM F562 | – | F 562 |
| – | – | – | – | – | – | – | – | – | – | ASTM F563 | – | F 563 |
| – | – | – | – | R30188 | – | KC22N22W14Fe | – | – | – | – | – | Haynes 188 |
| AlSl 670 | CoCr 20 W 15 Ni | – | – | – | – | KC20WN | – | – | – | – | – | HS 25 |
| – | CoCr 26 Ni 14 Mo | – | – | – | – | – | – | – | – | 5380 | – | HS 30 |
| – | CoCr 19 W 14 NiB | – | – | – | – | – | – | – | – | – | – | HS 36 |
| – | – | – | – | – | – | – | – | – | – | – | – | L 251 |
| – | CoCrW 10 TaZrB | – | – | – | – | KC21W10Ta9 | – | – | – | – | – | MAR-M 302 |
| – | CoCr 22 W 9 TaZrNb | – | – | – | – | KC21W9Ta | – | – | – | – | – | MAR-M 322 |
| – | CoCr 24 Ni 10 WTaZrB | – | – | – | – | KC23N10W7Ta | – | – | – | – | – | MAR-M 509 |
| – | – | – | – | – | – | KC20N20Ta7 | – | – | – | – | – | MAR-M 905 |
| – | CoCr 20 Ni 20 Ta | – | – | – | – | KC20N20Ta7 | – | – | – | – | – | MAR-M 918 |
| – | – | – | – | R30159 | – | – | – | – | – | – | – | MP159 |
| – | – | – | – | R30035 | – | – | – | – | – | – | – | MP35N |
| – | – | – | – | – | – | KC33W13 | – | – | – | – | – | Stellite 1 |
| – | – | – | – | – | – | KC28W8 | – | – | – | – | – | Stellite 12 |
| – | – | – | – | – | – | KC22N22W14Fe | – | – | – | – | – | Stellite 188 |
| – | – | – | – | – | – | KC26NW | – | – | – | – | – | Stellite 6 |
| – | – | – | – | – | – | – | – | – | – | – | – | Stellite 8 (F75) |
| – | CoCr 25 Ni 20 MoWNb | – | – | – | – | KC25N20DFeWNb | – | – | – | – | – | V-36 |
| – | CoCr 21 Mo 11 W | – | – | – | – | KC21W11ANbT | – | – | – | – | – | WI-52 |
| – | – | – | – | – | – | KC25N10W7Fe | – | – | – | – | – | X 45 |
| – | – | – | – | – | – | – | – | – | J-1570 | – | – | – |
| – | K13C20N126Fe15D7 | – | – | R3003иR3008 | – | K13C20N126Fe15D7 | – | – | – | ASTM F1058 | – | – |
