Державки Beyond™ Evolution™ для обработки торцевых канавок Державки Beyond™ Evolution ™ для обработки торцевых канавок
(Державки с прямоугольным хвостовиком для торцевых наружных канавок • Метрическая система — продолжение) (Державки с прямоугольным хвостовиком для торцевых наружных канавок • Метрическая система — продолжение)
поса- поса-
| номер | | дочный номер по | | D | D | W | | | | | | | | крепежный | |
| заказа | | размер каталогу | CD | max | min | min | B | H2 | L1 | FS | LH | | CF | CS винт Torx | Torx |
| 6124214 | EVSBR2525M0516075100C | 5 | 16 | 100 | 75 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124218 | EVSBR2525M0516100180C | 5 | 16 | 180 100 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124222 | EVSBR2525M0516180250C | 5 | 16 | 250 180 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124226 | EVSBR2525M0516250350C | 5 | 16 | 350 250 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124230 | EVSBR2525M0516350999C | 5 | 16 | 999 350 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124198 | EVSBR2525M0526050060C | 5 | 26 | 60 | 50 | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124212 | EVSBR2525M0526060075C | 5 | 26 | 60 | 60 | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124216 | EVSBR2525M0526075100C | 5 | 26 | 100 | 75 | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124235 | EVSBR3232P0532100180C | 5 | 32 | 180 100 | | 32 | 32 | 42 | 170 | 30 | 53 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124237 | EVSBR3232P0532180250C | 5 | 32 | 250 180 | | 32 | 32 | 42 | 170 | 30 | 53 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| номер | | дочный номер по | | D | D | W | | | | | | | | крепежный | |
| заказа | | размер каталогу | CD | max | min | min | B | H2 | L1 | FS | LH | | CF | CS винт Torx | Torx |
| 6116580 | EVSBL2525M0426100180C | 4 | 26 | 180 100 | | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116582 | EVSBL2525M0426180250C | 4 | 26 | 250 180 | | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080039 | EVSBL2525M0516050060C | 5 | 16 | 60 | 50 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124211 | EVSBL2525M0516060075C | 5 | 16 | 60 | 60 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124215 | EVSBL2525M0516075100C | 5 | 16 | 100 | 75 | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124219 | EVSBL2525M0516100180C | 5 | 16 | 180 100 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124223 | EVSBL2525M0516180250C | 5 | 16 | 250 180 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124227 | EVSBL2525M0516250350C | 5 | 16 | 350 250 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124232 | EVSBL2525M0516350999C | 5 | 16 | 999 350 | | 25 | 25 | 34 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124199 | EVSBL2525M0526050060C | 5 | 26 | 60 | 50 | 25 | 25 | 35 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| номер заказа | номер по каталогу | поса- дочный размер | CD | D max | D min | W min | B | H | 2 | L1 | FS | LH | CF | CS | крепежный винт Torx | Torx |
| 6116580 | EVSBL2525M0426100180C | 4 | 26 | 180 | 100 | 25 | 25 | 3 | 5 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6116582 | EVSBL2525M0426180250C | 4 | 26 | 250 | 180 | 25 | 25 | 3 | 5 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6080039 | EVSBL2525M0516050060C | 5 | 16 | 60 | 50 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124211 | EVSBL2525M0516060075C | 5 | 16 | 60 | 60 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124215 | EVSBL2525M0516075100C | 5 | 16 | 100 | 75 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124219 | EVSBL2525M0516100180C | 5 | 16 | 180 | 100 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124223 | EVSBL2525M0516180250C | 5 | 16 | 250 | 180 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124227 | EVSBL2525M0516250350C | 5 | 16 | 350 | 250 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124232 | EVSBL2525M0516350999C | 5 | 16 | 999 | 350 | 25 | 25 | 3 | 4 | 150 | 23 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124199 | EVSBL2525M0526050060C | 5 | 26 | 60 | 50 | 25 | 25 | 3 | 5 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124213 | EVSBL2525M0526060075C | 5 | 26 | 60 | 60 | 25 | 25 | 3 | 5 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124217 | EVSBL2525M0526075100C | 5 | 26 | 100 | 75 | 25 | 25 | 3 | 5 | 150 | 23 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124236 | EVSBL3232P0532100180C | 5 | 32 | 180 | 100 | 32 | 32 | 4 | 2 | 170 | 30 | 53 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124238 | EVSBL3232P0532180250C | 5 | 32 | 250 | 180 | 32 | 32 | 4 | 2 | 170 | 30 | 53 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124240 | EVSBL3232P0532250350C | 5 | 32 | 350 | 250 | 32 | 32 | 4 | 2 | 170 | 30 | 53 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124242 | EVSBL3232P0532350999C | 5 | 32 | 999 | 350 | 32 | 32 | 4 | 2 | 170 | 30 | 53 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124606 | EVSBL2525M0616060075C | 6 | 16 | 75 | 60 | 25 | 25 | 3 | 5 | 150 | 22 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124610 | EVSBL2525M0616075100C | 6 | 16 | 100 | 75 | 25 | 25 | 3 | 5 | 150 | 22 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124674 | EVSBL2525M0616100180C | 6 | 16 | 180 | 100 | 25 | 25 | 3 | 5 | 150 | 22 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124678 | EVSBL2525M0616180250C | 6 | 16 | 250 | 180 | 25 | 25 | 3 | 5 | 150 | 22 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124682 | EVSBL2525M0616250350C | 6 | 16 | 350 | 250 | 25 | 25 | 3 | 5 | 150 | 22 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124686 | EVSBL2525M0616350999C | 6 | 16 | 999 | 350 | 25 | 25 | 3 | 5 | 150 | 22 | 37 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124608 | EVSBL2525M0626060075C | 6 | 26 | 75 | 60 | 25 | 25 | 3 | 5 | 150 | 22 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124672 | EVSBL2525M0626075100C | 6 | 26 | 100 | 75 | 25 | 25 | 3 | 5 | 150 | 22 | 47 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1970 | T30 |
| 6124690 | EVSBL3232P0632100180C | 6 | 32 | 180 | 100 | 32 | 32 | 4 | 3 | 170 | 29 | 55 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1490 | T45 |
| 6124692 | EVSBL3232P0632180250C | 6 | 32 | 250 | 180 | 32 | 32 | 4 | 3 | 170 | 29 | 55 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1490 | T45 |
| 6124694 | EVSBL3232P0632250350C | 6 | 32 | 350 | 250 | 32 | 32 | 4 | 3 | 170 | 29 | 55 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1490 | T45 |
| 6124696 | EVSBL3232P0632350999C | 6 | 32 | 999 | 350 | 32 | 32 | 4 | 3 | 170 | 29 | 55 | 1/8 - 27 NPTF | 1/8 - 27 NPTF | MS1490 | T45 |
| установочный винт номер по каталогу | установочный винт номер заказа | моме Нм | нт затяжки дюйм-фунт | резьба | торцевая головка | ключ номер по каталогу | ключ номер заказа |
| MS1160 | 1099645 | 7 | 62 | M5 | T20 | KT20 | 1022703 |
| MS1162 | 1127019 | 9 | 80 | M6 | T25 | KT25 | 1022725 |
| MS1163 | 1124104 | 18 | 159 | M8 | T30 | KT30L | 1099676 |
| MS1273 | 1020977 | 4 | 35.4 | M4 | T15 | KT15 | 1022701 |
| MS1490 | 2263299 | 17 | 151 | M8 | T45 | KT45 | 1018227 |
| MS1595 | 1094300 | 12 | 106 | M6 | T30 | KT30 | 1099676 |
| MS1970 | 1106668 | 12 | 106 | M6 | T30 | KT30 | 1099676 |
| MS2002 | 1621087 | 9 | 80 | M6 | T25 | KT25 | 1022725 |
| MS2091 | 1931147 | 9 | 80 | M5 | 25IP | K25IP | 2050113 |
