TopSwiss MBS INSERTS
Расточка и профилирование
ХМ • Закаленные материалы
| Номер заказа | Каталоговый номер | D | DMIN (дюйм) | DMIN (мм) | L4 (дюйм) | L4 (мм) | L (дюйм) | L (мм) | R (дюйм) | R (мм) | Угол наклона | Задний угол | Применение |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7233132 | L4BPHM020C05R005 KCHS25S | 4 | 0.079 | 2.00 | 0.197 | 5 | 0.748 | 19 | 0.002 | 0.05 | 8.0° | 20° | • |
| 7233134 | L4BPHM020C10R005 KCHS25S | 4 | 0.079 | 2.00 | 0.394 | 10 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | • |
| 7233135 | L4BPHM020C15R005 KCHS25S | 4 | 0.079 | 2.00 | 0.591 | 15 | 1.142 | 29 | 0.002 | 0.05 | 8.0° | 20° | • |
| 7233136 | L4BPHM028C10R010 KCHS25S | 4 | 0.110 | 2.80 | 0.394 | 10 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233137 | L4BPHM028C16R010 KCHS25S | 4 | 0.110 | 2.80 | 0.630 | 16 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233151 | L4BPHM028C20R010 KCHS25S | 4 | 0.110 | 2.80 | 0.787 | 20 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233152 | L4BPHM040C10R010 KCHS25S | 4 | 0.158 | 4.00 | 0.394 | 10 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233153 | L4BPHM040C16R010 KCHS25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233154 | L4BPHM040C20R010 KCHS25S | 4 | 0.158 | 4.00 | 0.787 | 20 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233156 | L4BPHM040C24R010 KCHS25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233157 | L4BPHM040C28R010 KCHS25S | 4 | 0.158 | 4.00 | 1.102 | 28 | 1.654 | 42 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233158 | L5BPHM050C10R015 KCHS25S | 5 | 0.197 | 5.00 | 0.394 | 10 | 0.984 | 25 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233159 | L5BPHM050C15R015 KCHS25S | 5 | 0.197 | 5.00 | 0.591 | 15 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233160 | L5BPHM050C20R015 KCHS25S | 5 | 0.197 | 5.00 | 0.787 | 20 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233161 | L5BPHM050C25R015 KCHS25S | 5 | 0.197 | 5.00 | 0.984 | 25 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233162 | L5BPHM050C30R015 KCHS25S | 5 | 0.197 | 5.00 | 1.181 | 30 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233163 | L5BPHM050C35R015 KCHS25S | 5 | 0.197 | 5.00 | 1.378 | 35 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233164 | L6BPHM060C15R015 KCHS25S | 6 | 0.236 | 6.00 | 0.591 | 15 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233165 | L6BPHM060C22R015 KCHS25S | 6 | 0.236 | 6.00 | 0.866 | 22 | 1.457 | 37 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233166 | L6BPHM060C25R015 KCHS25S | 6 | 0.236 | 6.00 | 0.984 | 25 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233167 | L6BPHM060C30R015 KCHS25S | 6 | 0.236 | 6.00 | 1.181 | 30 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233168 | L6BPHM060C35R015 KCHS25S | 6 | 0.236 | 6.00 | 1.378 | 35 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233169 | L6BPHM060C42R015 KCHS25S | 6 | 0.236 | 6.00 | 1.654 | 42 | 2.244 | 57 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233170 | L7BPHM068C20R015 KCHS25S | 7 | 0.268 | 6.80 | 0.787 | 20 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233171 | L7BPHM068C25R015 KCHS25S | 7 | 0.268 | 6.80 | 0.984 | 25 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233172 | L7BPHM068C30R015 KCHS25S | 7 | 0.268 | 6.80 | 1.181 | 30 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233173 | L7BPHM068C35R015 KCHS25S | 7 | 0.268 | 6.80 | 1.378 | 35 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233174 | L7BPHM068C40R015 KCHS25S | 7 | 0.268 | 6.80 | 1.575 | 40 | 2.165 | 55 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233175 | L7BPHM068C45R015 KCHS25S | 7 | 0.268 | 6.80 | 1.772 | 45 | 2.362 | 60 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233176 | L7BPHM068C50R015 KCHS25S | 7 | 0.268 | 6.80 | 1.969 | 50 | 2.559 | 65 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233177 | R4BPHM020C05R005 KCHS25S | 4 | 0.079 | 2.00 | 0.197 | 5 | 0.748 | 19 | 0.002 | 0.05 | 8.0° | 20° | • |
| 7233179 | R4BPHM020C10R005 KCHS25S | 4 | 0.079 | 2.00 | 0.394 | 10 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | • |
| 7233180 | R4BPHM020C15R005 KCHS25S | 4 | 0.079 | 2.00 | 0.591 | 15 | 1.142 | 29 | 0.002 | 0.05 | 8.0° | 20° | • |
| 7233181 | R4BPHM028C10R010 KCHS25S | 4 | 0.110 | 2.80 | 0.394 | 10 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233183 | R4BPHM028C16R010 KCHS25S | 4 | 0.110 | 2.80 | 0.630 | 16 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233184 | R4BPHM028C20R010 KCHS25S | 4 | 0.110 | 2.80 | 0.787 | 20 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233185 | R4BPHM040C10R010 KCHS25S | 4 | 0.158 | 4.00 | 0.394 | 10 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233186 | R4BPHM040C16R010 KCHS25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233187 | R4BPHM040C20R010 KCHS25S | 4 | 0.158 | 4.00 | 0.787 | 20 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233188 | R4BPHM040C24R010 KCHS25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233189 | R4BPHM040C28R010 KCHS25S | 4 | 0.158 | 4.00 | 1.102 | 28 | 1.654 | 42 | 0.004 | 0.10 | 8.0° | 20° | • |
| 7233191 | R5BPHM050C10R015 KCHS25S | 5 | 0.197 | 5.00 | 0.394 | 10 | 0.984 | 25 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233192 | R5BPHM050C15R015 KCHS25S | 5 | 0.197 | 5.00 | 0.591 | 15 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233193 | R5BPHM050C20R015 KCHS25S | 5 | 0.197 | 5.00 | 0.787 | 20 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233194 | R5BPHM050C25R015 KCHS25S | 5 | 0.197 | 5.00 | 0.984 | 25 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233195 | R5BPHM050C30R015 KCHS25S | 5 | 0.197 | 5.00 | 1.181 | 30 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233196 | R5BPHM050C35R015 KCHS25S | 5 | 0.197 | 5.00 | 1.378 | 35 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233200 | R6BPHM060C25R015 KCHS25S | 6 | 0.236 | 6.00 | 0.984 | 25 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233201 | R6BPHM060C30R015 KCHS25S | 6 | 0.236 | 6.00 | 1.181 | 30 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233202 | R6BPHM060C35R015 KCHS25S | 6 | 0.236 | 6.00 | 1.378 | 35 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233203 | R6BPHM060C42R015 KCHS25S | 6 | 0.236 | 6.00 | 1.654 | 42 | 2.244 | 57 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233197 | R6BPHM060C15R015 KCHS25S | 6 | 0.236 | 6.00 | 0.590 | 15 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233199 | R6BPHM060C22R015 KCHS25S | 6 | 0.236 | 6.00 | 0.866 | 22 | 1.456 | 37 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233204 | R7BPHM068C20R015 KCHS25S | 7 | 0.268 | 6.80 | 0.787 | 20 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233205 | R7BPHM068C25R015 KCHS25S | 7 | 0.268 | 6.80 | 0.984 | 25 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233206 | R7BPHM068C30R015 KCHS25S | 7 | 0.268 | 6.80 | 1.181 | 30 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233207 | R7BPHM068C35R015 KCHS25S | 7 | 0.268 | 6.80 | 1.378 | 35 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233208 | R7BPHM068C40R015 KCHS25S | 7 | 0.268 | 6.80 | 1.575 | 40 | 2.165 | 55 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233209 | R7BPHM068C45R015 KCHS25S | 7 | 0.268 | 6.80 | 1.772 | 45 | 2.362 | 60 | 0.006 | 0.15 | 8.0° | 20° | • |
| 7233210 | R7BPHM068C50R015 KCHS25S | 7 | 0.268 | 6.80 | 1.969 | 50 | 2.559 | 65 | 0.006 | 0.15 | 8.0° | 20° | • |
