TopSwiss MBS INSERTS
Расточка и профилирование
МЛ • Медицинская линия
| Номер заказа | Каталоговый номер | D | DMIN (дюйм) | DMIN (мм) | L4 (дюйм) | L4 (мм) | L (дюйм) | L (мм) | R (дюйм) | R (мм) | Угол наклона | Задний угол | Применение |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7233060 | L4BPML005H02R002 KCSM25S | 4 | 0.020 | 0.50 | 0.079 | 2 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233082 | L4BPML008H04R002 KCSM25S | 4 | 0.032 | 0.80 | 0.158 | 4 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233083 | L4BPML010H05R002 KCSM25S | 4 | 0.039 | 1.00 | 0.197 | 5 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233084 | L4BPML010H07R002 KCSM25S | 4 | 0.039 | 1.00 | 0.276 | 7 | 0.866 | 22 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233085 | L4BPML015H05R002 KCSM25S | 4 | 0.059 | 1.50 | 0.197 | 5 | 0.748 | 19 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233086 | L4BPML015H10R002 KCSM25S | 4 | 0.059 | 1.50 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233087 | L4BPML020H05R002 KCSM25S | 4 | 0.079 | 2.00 | 0.197 | 5 | 0.748 | 19 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233088 | L4BPML020H10R002 KCSM25S | 4 | 0.079 | 2.00 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233089 | L4BPML025H05R002 KCSM25S | 4 | 0.098 | 2.50 | 0.197 | 5 | 0.748 | 19 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233090 | L4BPML025H10R002 KCSM25S | 4 | 0.098 | 2.50 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233091 | L4BPML030H10R002 KCSM25S | 4 | 0.118 | 3.00 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233093 | L4BPML030H16R002 KCSM25S | 4 | 0.118 | 3.00 | 0.630 | 16 | 1.181 | 30 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233094 | L4BPML035H10R002 KCSM25S | 4 | 0.138 | 3.50 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233096 | L4BPML035H16R002 KCSM25S | 4 | 0.138 | 3.50 | 0.630 | 16 | 1.181 | 30 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233097 | L4BPML035H20R002 KCSM25S | 4 | 0.138 | 3.50 | 0.787 | 20 | 1.339 | 34 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233098 | L4BPML040H10R002 KCSM25S | 4 | 0.158 | 4.00 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233099 | L4BPML040H16R002 KCSM25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233100 | L4BPML040H20R002 KCSM25S | 4 | 0.158 | 4.00 | 0.787 | 20 | 1.339 | 34 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233101 | L4BPML040H24R002 KCSM25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233102 | R4BPML005H02R002 KCSM25S | 4 | 0.020 | 0.50 | 0.079 | 2 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233103 | R4BPML008H04R002 KCSM25S | 4 | 0.032 | 0.80 | 0.158 | 4 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233104 | R4BPML010H05R002 KCSM25S | 4 | 0.039 | 1.00 | 0.197 | 5 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233105 | R4BPML010H07R002 KCSM25S | 4 | 0.039 | 1.00 | 0.276 | 7 | 0.866 | 22 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233106 | R4BPML015H05R002 KCSM25S | 4 | 0.059 | 1.50 | 0.197 | 5 | 0.748 | 19 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233107 | R4BPML015H10R002 KCSM25S | 4 | 0.059 | 1.50 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233108 | R4BPML020H05R002 KCSM25S | 4 | 0.079 | 2.00 | 0.197 | 5 | 0.748 | 19 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233109 | R4BPML020H10R002 KCSM25S | 4 | 0.079 | 2.00 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233110 | R4BPML025H05R002 KCSM25S | 4 | 0.098 | 2.50 | 0.197 | 5 | 0.748 | 19 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233111 | R4BPML025H10R002 KCSM25S | 4 | 0.098 | 2.50 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233112 | R4BPML030H10R002 KCSM25S | 4 | 0.118 | 3.00 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233113 | R4BPML030H16R002 KCSM25S | 4 | 0.118 | 3.00 | 0.630 | 16 | 1.181 | 30 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233114 | R4BPML035H10R002 KCSM25S | 4 | 0.138 | 3.50 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233115 | R4BPML035H16R002 KCSM25S | 4 | 0.138 | 3.50 | 0.630 | 16 | 1.181 | 30 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233116 | R4BPML035H20R002 KCSM25S | 4 | 0.138 | 3.50 | 0.787 | 20 | 1.339 | 34 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233117 | R4BPML040H10R002 KCSM25S | 4 | 0.158 | 4.00 | 0.394 | 10 | 0.945 | 24 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233119 | R4BPML040H16R002 KCSM25S | 4 | 0.158 | 4.00 | 0.630 | 16 | 1.181 | 30 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233120 | R4BPML040H20R002 KCSM25S | 4 | 0.158 | 4.00 | 0.787 | 20 | 1.339 | 34 | 0.001 | 0.02 | 8.0° | 11° | • |
| 7233131 | R4BPML040H24R002 KCSM25S | 4 | 0.158 | 4.00 | 0.945 | 24 | 1.496 | 38 | 0.001 | 0.02 | 8.0° | 11° | • |
