TopSwiss MBS INSERTS
Области применения
Растачивание и профилирование (продолжение)
Марка: KCU25S | Тип: GA
| Номер заказа | Номер каталога | D | DMIN | L4 | L | R | Угол подъема | Угол заднего плана | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| дюйм | мм | дюйм | мм | дюйм | мм | дюйм | мм | дюйм | мм | ||||
| 7219800 | R4BPGA028C16R010 | 0.110 | 2.80 | 0.591 | 15.00 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220107 | R4BPGA028C20R005 | 0.110 | 2.80 | 0.748 | 19.00 | 1.339 | 34 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219811 | R4BPGA028C20R010 | 0.110 | 2.80 | 0.748 | 19.00 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220097 | R4BPGA02XC05R005 | 0.079 | 2.00 | 0.177 | 4.50 | 0.748 | 19 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7220099 | R4BPGA02XC10R005 | 0.079 | 2.00 | 0.354 | 9.00 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7220101 | R4BPGA02XC15R005 | 0.079 | 2.00 | 0.551 | 14.00 | 1.142 | 29 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219812 | R4BPGA035C10R010 | 0.138 | 3.50 | 0.354 | 9.00 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7219813 | R4BPGA035C16R010 | 0.138 | 3.50 | 0.591 | 15.00 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7219814 | R4BPGA035C20R010 | 0.138 | 3.50 | 0.748 | 19.00 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7219815 | R4BPGA035C24R010 | 0.138 | 3.50 | 0.906 | 23.00 | 1.496 | 38 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220109 | R4BPGA040C10R005 | 0.158 | 4.00 | 0.354 | 9.00 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219817 | R4BPGA040C10R010 | 0.158 | 4.00 | 0.354 | 9.00 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220111 | R4BPGA040C16R005 | 0.158 | 4.00 | 0.591 | 15.00 | 1.181 | 30 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219818 | R4BPGA040C16R010 | 0.158 | 4.00 | 0.591 | 15.00 | 1.181 | 30 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220113 | R4BPGA040C20R005 | 0.158 | 4.00 | 0.748 | 19.00 | 1.339 | 34 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219819 | R4BPGA040C20R010 | 0.158 | 4.00 | 0.748 | 19.00 | 1.339 | 34 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220115 | R4BPGA040C24R005 | 0.158 | 4.00 | 0.906 | 23.00 | 1.496 | 38 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219820 | R4BPGA040C24R010 | 0.158 | 4.00 | 0.906 | 23.00 | 1.496 | 38 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220117 | R4BPGA040C28R005 | 0.158 | 4.00 | 1.063 | 27.00 | 1.654 | 42 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219821 | R4BPGA040C28R010 | 0.158 | 4.00 | 1.063 | 27.00 | 1.654 | 42 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220119 | R5BPGA050C10R005 | 0.197 | 5.00 | 0.354 | 9.00 | 0.984 | 25 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219822 | R5BPGA050C10R015 | 0.197 | 5.00 | 0.354 | 9.00 | 0.984 | 25 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220121 | R5BPGA050C15R005 | 0.197 | 5.00 | 0.551 | 14.00 | 1.181 | 30 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219823 | R5BPGA050C15R015 | 0.197 | 5.00 | 0.551 | 14.00 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220123 | R5BPGA050C20R005 | 0.197 | 5.00 | 0.748 | 19.00 | 1.378 | 35 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219824 | R5BPGA050C20R015 | 0.197 | 5.00 | 0.748 | 19.00 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220125 | R5BPGA050C25R005 | 0.197 | 5.00 | 0.945 | 24.00 | 1.575 | 40 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219825 | R5BPGA050C25R015 | 0.197 | 5.00 | 0.945 | 24.00 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220127 | R5BPGA050C30R005 | 0.197 | 5.00 | 1.142 | 29.00 | 1.772 | 45 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219826 | R5BPGA050C30R015 | 0.197 | 5.00 | 1.142 | 29.00 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220129 | R5BPGA050C35R005 | 0.197 | 5.00 | 1.339 | 34.00 | 1.969 | 50 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219827 | R5BPGA050C35R015 | 0.197 | 5.00 | 1.339 | 34.00 | 1.969 | 50 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7219828 | R5BPGA050C40R015 | 0.197 | 5.00 | 1.535 | 39.00 | 2.165 | 55 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220131 | R6BPGA060C15R005 | 0.236 | 6.00 | 0.551 | 14.00 | 1.181 | 30 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219829 | R6BPGA060C15R015 | 0.236 | 6.00 | 0.551 | 14.00 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220133 | R6BPGA060C22R005 | 0.236 | 6.00 | 0.827 | 21.00 | 1.457 | 37 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219830 | R6BPGA060C22R015 | 0.236 | 6.00 | 0.827 | 21.00 | 1.457 | 37 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220135 | R6BPGA060C25R005 | 0.236 | 6.00 | 0.945 | 24.00 | 1.575 | 40 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219831 | R6BPGA060C25R015 | 0.236 | 6.00 | 0.945 | 24.00 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220137 | R6BPGA060C30R005 | 0.236 | 6.00 | 1.142 | 29.00 | 1.772 | 45 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219832 | R6BPGA060C30R015 | 0.236 | 6.00 | 1.142 | 29.00 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220139 | R6BPGA060C35R005 | 0.236 | 6.00 | 1.339 | 34.00 | 1.969 | 50 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219833 | R6BPGA060C35R015 | 0.236 | 6.00 | 1.339 | 34.00 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220141 | R6BPGA060C42R005 | 0.236 | 6.00 | 1.614 | 41.00 | 2.244 | 57 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219834 | R6BPGA060C42R015 | 0.236 | 6.00 | 1.614 | 41.00 | 2.244 | 57 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219835 | R7BPGA068C20R015 | 0.268 | 6.80 | 0.748 | 19.00 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219836 | R7BPGA068C25R015 | 0.268 | 6.80 | 0.945 | 24.00 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219837 | R7BPGA068C30R015 | 0.268 | 6.80 | 1.142 | 29.00 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219838 | R7BPGA068C35R015 | 0.268 | 6.80 | 1.339 | 34.00 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219839 | R7BPGA068C40R015 | 0.268 | 6.80 | 1.535 | 39.00 | 2.165 | 55 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219840 | R7BPGA068C45R015 | 0.268 | 6.80 | 1.732 | 44.00 | 2.362 | 60 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219841 | R7BPGA068C50R015 | 0.268 | 6.80 | 1.929 | 49.00 | 2.559 | 65 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219843 | R8BPGA078C50R020 | 0.307 | 7.80 | 1.929 | 49.00 | 2.756 | 70 | 0.008 | 0.20 | 8.0° | 20° | ||
| 7219844 | R8BPGA078C60R020 | 0.307 | 7.80 | 2.323 | 59.00 | 3.150 | 80 | 0.008 | 0.20 | 8.0° | 20° | ||
