TopSwiss MBS INSERTS
Области применения
Растачивание и профилирование (продолжение)
Марка: KCU25S | Тип: GA
Легенда применения: P, M — основное; K, N, S, H — вторичное
| Номер заказа | Номер каталога | D | DMIN | L4 | L | R | Угол подъема | Угол заднего плана | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| дюйм | мм | дюйм | мм | дюйм | мм | дюйм | мм | дюйм | мм | ||||
| 7219760 | L5BPGA050C25R015 | 0.197 | 5.00 | 0.945 | 24.00 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220081 | L5BPGA050C30R005 | 0.197 | 5.00 | 1.142 | 29.00 | 1.772 | 45 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219761 | L5BPGA050C30R015 | 0.197 | 5.00 | 1.142 | 29.00 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220083 | L5BPGA050C35R005 | 0.197 | 5.00 | 1.339 | 34.00 | 1.969 | 50 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219762 | L5BPGA050C35R015 | 0.197 | 5.00 | 1.339 | 34.00 | 1.969 | 50 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7219763 | L5BPGA050C40R015 | 0.197 | 5.00 | 1.535 | 39.00 | 2.165 | 55 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220085 | L6BPGA060C15R005 | 0.236 | 6.00 | 0.551 | 14.00 | 1.181 | 30 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219764 | L6BPGA060C15R015 | 0.236 | 6.00 | 0.551 | 14.00 | 1.181 | 30 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220087 | L6BPGA060C22R005 | 0.236 | 6.00 | 0.827 | 21.00 | 1.457 | 37 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219765 | L6BPGA060C22R015 | 0.236 | 6.00 | 0.827 | 21.00 | 1.457 | 37 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220089 | L6BPGA060C25R005 | 0.236 | 6.00 | 0.945 | 24.00 | 1.575 | 40 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219766 | L6BPGA060C25R015 | 0.236 | 6.00 | 0.945 | 24.00 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220091 | L6BPGA060C30R005 | 0.236 | 6.00 | 1.142 | 29.00 | 1.772 | 45 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219767 | L6BPGA060C30R015 | 0.236 | 6.00 | 1.142 | 29.00 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220093 | L6BPGA060C35R005 | 0.236 | 6.00 | 1.339 | 34.00 | 1.969 | 50 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219769 | L6BPGA060C35R015 | 0.236 | 6.00 | 1.339 | 34.00 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7220095 | L6BPGA060C42R005 | 0.236 | 6.00 | 1.614 | 41.00 | 2.244 | 57 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219770 | L6BPGA060C42R015 | 0.236 | 6.00 | 1.614 | 41.00 | 2.244 | 57 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219771 | L7BPGA068C20R015 | 0.268 | 6.80 | 0.748 | 19.00 | 1.378 | 35 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219772 | L7BPGA068C25R015 | 0.268 | 6.80 | 0.945 | 24.00 | 1.575 | 40 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219773 | L7BPGA068C30R015 | 0.268 | 6.80 | 1.142 | 29.00 | 1.772 | 45 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219774 | L7BPGA068C35R015 | 0.268 | 6.80 | 1.339 | 34.00 | 1.969 | 50 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219775 | L7BPGA068C40R015 | 0.268 | 6.80 | 1.535 | 39.00 | 2.165 | 55 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219776 | L7BPGA068C45R015 | 0.268 | 6.80 | 1.732 | 44.00 | 2.362 | 60 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219777 | L7BPGA068C50R015 | 0.268 | 6.80 | 1.929 | 49.00 | 2.559 | 65 | 0.006 | 0.15 | 8.0° | 20° | ||
| 7219778 | L8BPGA078C50R020 | 0.307 | 7.80 | 1.929 | 49.00 | 2.756 | 70 | 0.008 | 0.20 | 8.0° | 20° | ||
| 7219779 | L8BPGA078C60R020 | 0.307 | 7.80 | 2.323 | 59.00 | 3.150 | 80 | 0.008 | 0.20 | 8.0° | 20° | ||
| 7219780 | R4BPGA003C01R002 | 0.012 | 0.30 | 0.047 | 1.20 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 20° | ||
| 7219781 | R4BPGA004C01R002 | 0.016 | 0.40 | 0.063 | 1.60 | 0.787 | 20 | 0.001 | 0.02 | 8.0° | 20° | ||
| 7219782 | R4BPGA005C02R004 | 0.020 | 0.50 | 0.071 | 1.80 | 0.787 | 20 | 0.002 | 0.04 | 8.0° | 20° | ||
| 7219783 | R4BPGA006C02R004 | 0.024 | 0.60 | 0.071 | 1.80 | 0.787 | 20 | 0.002 | 0.04 | 8.0° | 20° | ||
| 7219784 | R4BPGA006C03R004 | 0.024 | 0.60 | 0.079 | 2.00 | 0.787 | 20 | 0.002 | 0.04 | 8.0° | 20° | ||
| 7219785 | R4BPGA008C04R004 | 0.032 | 0.80 | 0.150 | 3.80 | 0.787 | 20 | 0.002 | 0.04 | 8.0° | 20° | ||
| 7219786 | R4BPGA010C05R005 | 0.039 | 1.00 | 0.177 | 4.50 | 0.787 | 20 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219787 | R4BPGA010C07R005 | 0.039 | 1.00 | 0.256 | 6.50 | 0.866 | 22 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219788 | R4BPGA010C08R005 | 0.039 | 1.00 | 0.295 | 7.50 | 0.866 | 22 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219789 | R4BPGA015C05R005 | 0.059 | 1.50 | 0.177 | 4.50 | 0.748 | 19 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219790 | R4BPGA015C10R005 | 0.059 | 1.50 | 0.354 | 9.00 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219791 | R4BPGA015C12R005 | 0.059 | 1.50 | 0.433 | 11.00 | 1.024 | 26 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219792 | R4BPGA020C05R005 | 0.079 | 2.00 | 0.177 | 4.50 | 0.748 | 19 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219794 | R4BPGA020C10R005 | 0.079 | 2.00 | 0.354 | 9.00 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219795 | R4BPGA020C15R005 | 0.079 | 2.00 | 0.551 | 14.00 | 1.142 | 29 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219796 | R4BPGA025C05R005 | 0.098 | 2.50 | 0.177 | 4.50 | 0.748 | 19 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219797 | R4BPGA025C10R005 | 0.098 | 2.50 | 0.354 | 9.00 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219798 | R4BPGA025C16R005 | 0.098 | 2.50 | 0.591 | 15.00 | 1.181 | 30 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7220103 | R4BPGA028C10R005 | 0.110 | 2.80 | 0.354 | 9.00 | 0.945 | 24 | 0.002 | 0.05 | 8.0° | 20° | ||
| 7219799 | R4BPGA028C10R010 | 0.110 | 2.80 | 0.354 | 9.00 | 0.945 | 24 | 0.004 | 0.10 | 8.0° | 20° | ||
| 7220105 | R4BPGA028C16R005 | 0.110 | 2.80 | 0.591 | 15.00 | 1.181 | 30 | 0.002 | 0.05 | 8.0° | 20° | ||
