HSK80 D1 D2 D21 L1 L2 G5 Order Number Catalog Number mm in mm in mm in mm in mm in 7138027 HSK80AHCP16190M 16,00 .630 37,50 1.476 49,85 1.963 190,00 7.480 125,00 4.921 M10 7138028 HSK80AHCP20170M 20,00 .787 41,50 1.634 49,85 1.963 170,00 6.693 105,00 4.134 M10 7138029 HSK80AHCP25150M 25,00 .984 49,90 1.965 62,85 2.474 150,00 5.906 85,00 3.347 M12 7138030 HSK80AHCP32130M 32,00 1.260 59,90 2.358 62,85 2.474 130,00 5.118 65,00 2.559 M12 DRILLS D1 D1 Max L1 D L4 G5 Insert Seat Order Number Catalog Number mm in mm in mm in mm in mm in Size (SSC) 7138070 KSEM125ST090SFP16M 12,000 .4922 13,500 .5314 90,00 3.543 16,00 0.630 50,00 1.969 M10 C 7138081 KSEM136ST090SFP16M 13,501 .5315 13,999 .5511 90,00 3.543 16,00 0.630 50,00 1.969 M10 B 7138082 KSEM140ST110SFP20M 14,000 .5512 14,500 .5708 110,00 4.331 20,00 0.787 64,00 2.520 M10 B 7138083 KSEM146ST110SFP20M 14,501 .5709 15,874 .6249 110,00 4.331 20,00 0.787 64,00 2.520 M10 A 7138084 KSEM158ST110SFP20M 15,875 .6250 16,999 .6692 110,00 4.331 20,00 0.787 63,50 2.500 M10 1 7138085 KSEM170ST110SFP20M 17,000 .6693 17,999 .7086 110,00 4.331 20,00 0.787 63,00 2.480 M10 1 7138086 KSEM180ST110SFP20M 18,000 .7087 18,000 .7087 110,00 4.331 20,00 0.787 62,50 2.461 M10 1 7138087 KSEM181ST110SFP20M 18,001 .7087 18,999 .7480 110,00 4.331 20,00 0.787 62,50 2.461 M10 2 7138088 KSEM190ST110SFP20M 19,000 .7481 19,999 .7874 110,00 4.331 20,00 0.787 62,50 2.461 M10 2 7138089 KSEM200ST110SFP20M 20,000 .7875 20,999 .8267 110,00 4.331 20,00 0.787 62,00 2.441 M10 3 7138090 KSEM210ST110SFP20M 21,000 .8268 21,999 .8661 110,00 4.331 20,00 0.787 61,50 2.421 M10 3 7138101 KSEM220ST110SFP20M 22,000 .8661 22,000 .8661 110,00 4.331 20,00 0.787 61,50 2.421 M10 3 7138102 KSEM221ST130SFP25M 22,001 .8662 22,999 .9055 130,00 5.118 25,00 0.984 74,50 2.933 M12 4 7138103 KSEM230ST130SFP25M 23,000 .9056 23,999 .9448 130,00 5.118 25,00 0.984 74,00 2.913 M12 4 7138104 KSEM240ST130SFP25M 24,000 .9449 24,000 .9449 130,00 5.118 25,00 0.984 74,00 2.913 M12 4 7138105 KSEM241ST130SFP25M 24,001 .9449 24,999 .9842 130,00 5.118 25,00 0.984 74,00 2.913 M12 5 7138106 KSEM250ST130SFP25M 25,000 .9843 25,999 1.0236 130,00 5.118 25,00 0.984 73,50 2.894 M12 5 7138107 KSEM260ST130SFP25M 26,000 1.0236 26,000 1.0236 130,00 5.118 25,00 0.984 73,00 2.874 M12 5 7138108 KSEM261ST130SFP25M 26,001 1.0237 27,999 1.1023 130,00 5.118 25,00 0.984 73,00 2.874 M12 6 7138109 KSEM280ST130SFP25M 28,000 1.1024 28,000 1.1024 130,00 5.118 25,00 0.984 72,50 2.854 M12 6 7138110 KSEM281ST150SFP32M 28,001 1.1024 29,999 1.1810 150,00 5.906 32,00 1.260 84,50 3.327 M12 7 7138111 KSEM300ST150SFP32M 30,000 1.1811 30,000 1.1811 150,00 5.906 32,00 1.260 84,00 3.307 M12 7 7138112 KSEM301ST150SFP32M 30,001 1.1812 31,999 1.2598 150,00 5.906 32,00 1.260 84,00 3.307 M12 8 7138113 KSEM320ST150SFP32M 32,000 1.2598 32,000 1.2598 150,00 5.906 32,00 1.260 83,50 3.287 M12 8 7138114 KSEM321ST150SFP32M 32,001 1.2599 32,999 1.2992 150,00 5.906 32,00 1.260 83,50 3.287 M12 9 7138115 KSEM330ST150SFP32M 33,000 1.2993 36,000 1.4173 150,00 5.906 32,00 1.260 83,00 3.268 M12 9 4
