D2 b BBH 63 Extension Slides for MB Modular L BHE Fine Boring Holders L1 D1 kg ITS BORE Designation D 1 L 1 L D 2 b BBH 63X78 32.00 66.0 78.00 63.00 28.0 0.515 For tools, see pages: IHFF (786) • IHRF (787) b H1 BHEH Slides for MB Modular BHE Fine Boring Holders d2 L kg Designation H 1 b L d 2 BHEH 24X75 14.5 24.0 75.00 - 0.200 BHEH 28X80 22.5 28.0 80.00 16.00 0.334 BHEH 28X108 22.5 28.0 108.00 - 0.525 BHEH 28X148 22.5 28.0 148.00 - 0.695 For tools, see pages: IHFF (786) • IHRF (787) • IHRF-BW (789) • IHRF-CH (790) D2 b ADBH Sleeve for MB Modular L Fine Boring Holders D1 d2 kg Designation D 1 L D 2 b d 2 ADBH 30XD16 30.00 25.00 39.00 30.5 16.00 0.150 For tools, see pages: IHAXF (783) • IHAXF-AVI (784) • IHAXF-E (784) 22 17 CW32 Counter Balancing Weight Used on BHEH Slide for Fine Boring Holders L kg Designation L CW32 31.50 0.054 IHFF f Triangular Insert Holders for Mounting on MB Fine Boring Heads 91° l1 Designation f l 1 d min d max Insert IHFF 25 10.0 26.50 28.0 40.0 TPGX 0902... SR 14-298 T-8/5 IHFF 32 11.5 34.50 35.0 53.0 TPGX 0902... SR 14-298 T-8/5 IHFF 40 14.0 44.60 48.0 66.0 TPGX 1103... SR-17979 M3X8 T-8/5 IHFF 50 19.0 52.00 54.0 86.0 TPGX 1103... SR-17979 M3X8 T-8/5 For inserts, see pages: TPGX (807) • TPGX (CBN) (808) For holders, see pages: BBH 30/40 (785) • BBH 63 (786) • BBH D16 (785) • BHD 50 L200 (787) • BHD MB (766) • BHE MB (770) • BHEH (786) • BHF L200 (787) • BHF MB16-MB50 Dia. 6-108 (774) • BHFH (785) 786 ISCAR
