USER GUIDE Requested Information Form for Deep Hole Drill Design Company name Telephone no. Address Date Contact person Customer no. WORKPIECE Product name: Hole diameter: Hole depth: No. of holes: Tolerance (of hole): DEEP HOLE DRILLING Surface finish (Rz, Ra...): Deviation (mm/100): Straightness (mm/100): MATERIAL Material (DIN, AISI, JIS...): Hardness (HB, HS, HRC...): Condition: o Annealed o Quenched o Tempered o Cast o Other MACHINE Machine supplier name: Machine type/model: o NC lathe o Machining center o Other Rigidity: o Good o Normal o Poor Spindle power (kW): Tool and/or workpiece rotation (TR/WR): o Tool and workpiece o Rotating workpiece (WR) o Rotating tool (TR) TYPE OF COOLANT Water based: o Soluble o Emulsion % Oil based: o Coolant Pressure (bar): Coolant Volume (L/min): TOOL Drill Head Drill diameter: (mm/inch) Thread: Brazed: o o Inner o Outer Indexable: Coating: o Coated o Uncoated o Adjustable o Direct mount Solid drilling: Counterboring: o o Pre-drilled hole size: (mm/inch) Bottom finishing: o Full ball R o Flat bottom R o Corner R o Other Trepanning: o Y o N Tube outer diameter: (mm/inch) Core size diameter: (mm/inch) Please fill in and return to your ISCAR representative. 646 646 ISCAR ISCAR
