| Material Groups | Tensile | Hardness | Material | Recomm | en | ded | Ma | S Feed chin | UMO vs. Dr 1.9 ing | CHA ill Di 3.9 Con | M amet 5.9 diti | er 9.9 ons | 5.9 | 2.9 | |
| O Material | Condition | Strength [N/mm2] | HB | No.(1) | V m/min | D=4-4.9 | D=5-5.9 | D=6-7.9 | D=8-9.9 | D=10-1 | D=12-1 | D=14-1 | D=16-1 | D=20-2 | D=26-3 |
| IS | m | m/rev | |||||||||||||
| < 0.25 %C | Annealed | 420 | 125 | 1 | 80-110-140 | ||||||||||
| Non-alloy ≥ 0.25 %C | Annealed | 650 | 190 | 2 | 80-105-130 | ||||||||||
| steel and cast steel free < 0.55 %C | Quenched and tempered | 850 | 250 | 3 | 80-100-120 | 0.04 0.06 | 0.07 0.09 | 0.09 0.11 | 0.12 0.17 | 0.15 0.21 | 0.18 0.2 | 4 0.20 0.27 | 0.25 0.35 | 0.25 0.35 | 0.30 0.40 |
| , cutting steel | Annealed | 750 | 220 | 4 | 70-90-110 | 0.08 | 0.11 | 0.13 | 0.22 | 0.28 | 0.30 | 0.35 | 0.45 | 0.45 | 0.50 |
| ≥ 0.55 %C | Quenched and tempered | 1000 | 300 | 5 | 50-70-90 | ||||||||||
| Annealed | 600 | 200 | 6 | 80-100-120 | |||||||||||
| P Low alloy and cast | 930 | 275 | 7 | 70-90-110 | 0.04 | 0.07 | 0.09 | 0.12 | 0.14 | 0.16 | 0.18 | 0.23 | 0.25 | 0.30 | |
| steel (less than 5% of | Quenched and | 1000 | 300 | 8 | 50-70-90 | 0.06 | 0.09 | 0.12 | 0.18 | 0.21 | 0.2 | 4 0.26 | 0.31 | 0.35 | 0.40 |
| alloying elements) | tempered | 1200 | 350 | 9 | 40-55-70 | 0.08 | 0.11 | 0.15 | 0.25 | 0.28 | 0.32 | 0.35 | 0.40 | 0.45 | 0.50 |
| High alloyed steel cast | Annealed | 680 | 200 | 10 | 50-70-90 | 0.06 | 0.07 | 0.09 | 0.12 | 0.12 | 0.15 | 0.18 | 0.20 | 0.22 | 0.25 |
| , steel and tool steel | Quenched and tempered | 1100 | 325 | 11 | 40-60-80 | 0.07 0.08 | 0.09 0.10 | 0.11 0.12 | 0.16 0.20 | 0.17 0.22 | 0.2 0.25 | 0.23 0.28 | 0.25 0.30 | 0.27 0.33 | 0.30 0.35 |
| Stainless steel and cast steel | Ferritic/ martensitic | 680 | 200 | 12 | 40-55-70 | 0.05 0.06 | 0.06 0.07 | 0.08 0.10 | 0.11 0.15 | 0.11 0.16 | 0.14 0.1 | 9 0.17 0.22 | 0.22 0.24 | 0.21 0.26 | 0.24 0.29 |
| Martensitic | 820 | 240 | 13 | 0.07 | 0.08 | 0.11 | 0.19 | 0.21 | 0.24 | 0.27 | 0.29 | 0.32 | 0.34 | ||
| Gray cast iron (GG) | Ferritic / pearlitic | 180 | 15 | 90-125-160 | |||||||||||
| Pearlitic / | |||||||||||||||
| martensitic | 260 | 16 | 80-110-140 | 0.04 | 0.10 | 0.12 | 0.15 | 0.20 | 0.25 | 0.30 | 0.35 | 0.35 | 0.40 | ||
| K | Ferritic | 160 | 17 | 90-135-180 | 0.06 | 0.13 | 0.15 | 0.22 | 0.27 | 0.3 | 2 0.37 | 0.45 | 0.47 | 0.50 | |
| Nodular cast iron (GGG) | 0.08 | 0.15 | 0.18 | 0.30 | 0.35 | 0.40 | 0.45 | 0.55 | 0.60 | 0.60 | |||||
| Pearlitic | 250 | 18 | 80-110-140 | ||||||||||||
| Malleable cast iron | Ferritic | 130 | 19 | 90-125-160 | |||||||||||
| Pearlitic | 230 | 20 | 80-110-140 |
Recommended cutting data (1) For workpiece materials list, see pages 495-524 . As a starting value, the middle of the recommended machining range should be used. Then, according to the wear results, conditions can be changed to optimize performance. The data refers to IC908
- When using external coolant supply only, reduce cutting speed by 10%
- When using more than 5XD drill ratio, reduce cutting parameters by 10%
No need to reduce the cutting parameters while using 8XD and up holders
