| GADR-8 | |||||||||||||
| GHAR/L-8 External Holders for Groo and Turning Adapters | ving | LH | HF OHX | HB | OAL H H | ||||||||
| GAFG | -L-8 | WF(asse | mbly) WF (holder) | CDX | B GHAR | Right-hand s | hown | ||||||
| Designation | H | HF | B | WF(1) | OAL | LH | OHX(2) | HBH TGA(3) | CDX(4) | FG(5) | |||
| GHAR/L 25-8 | 25.0 | 25.0 | 25.0 | 16.0 | 124.50 | 45.0 | 25.50 | 14.0 GADR/L 8 | 25.50 | GAFG...R/L-8 | SR 14-519 | T-20/5 SR M6X25 DIN912 | HW 5.0 |
| GHAR/L 32-8 | 32.0 | 32.0 | 32.0 | 23.0 | 144.50 | 45.0 | 25.50 | 7.0 GADR/L 8 | 25.50 | GAFG...R/L-8 | SR 14-519 | T-20/5 SR M6X25 DIN912 | HW 5.0 |
- Adapters GADR/L-8 for turning and grooving, GAFG-R/L-8 for face-grooving (to be ordered separately)
(1) WF(holder) (2) Maximum overhang (3) Adapter for Turning & Grooving (4) See specific adapter dimensions (5) Adapter for Face Grooving
For tools, see pages: GADR/L-8 (286) GAFG-R/L-8 (580) PCADR/L 34N-RE (318)
| GHAPR/L-8 External Holders for Grooving and Turning Perpendicularly Oriented Adapters | HF | OAL LH HBH CDX | H B | ||||||
| GAFG… | R-8 | GADL8 GHAPR | Right-hand shown | ||||||
| Designation H | HF | B | OAL | LH | HBH | TGA(1) | CDX(2) FG(3) | ||
| GHAPR/L 32-8 32.0 | 32.0 | 32.0 | 155.00 | 30.0 | 7.0 G | ADR/L 8 | 25.50 GAFG...R/L-8 | SR 14-519 | T-20/5 SR M6X25 DIN912 HW 5.0 |
- Adapters GADR/L-8 for turning and grooving, GAFG-R/L-8 for face-grooving (to be ordered separately)
(1) Adapter for Turning & Grooving (2) See specific adapter dimensions (3) Adapter for Face Grooving
For tools, see pages: GADR/L-8 (286) GAFG-R/L-8 (580) PCADR/L 34N-RE (318)
| GAFG-R/L-8 Adapters for Face Machining | DAXN-DAX CDX | X OAH HF OAL WF CW CDX | GAFG-...L8 For face gr | ooving | Left-hand shown | |||
| Designation | CW | DAXN(1) | DAXX(2) | CDX(3) | WF | HF | OAH | OAL |
| GAFG 80R/L-8 | 8.00 | 80.0 | 115.0 | 23.00 | 9.00 | 32.0 | 42.0 | 63.50 |
| GAFG 105R/L-8 | 8.00 | 105.0 | 160.0 | 25.00 | 9.00 | 32.0 | 42.0 | 63.50 |
| GAFG 155R/L-8 | 8.00 | 155.0 | 510.0 | 25.00 | 9.00 | 32.0 | 42.0 | 63.50 |
- No limitation for widening the groove either way after initial grooving
- For user guide, see pages 604-613
(1) Minimum penetration diameter (2) Maximum penetration diameter (3) For GIFG-8 & GDMY-8 CDX=25 mm for DAX range
For inserts, see pages: GDMA (300) GDMF (288) GDMM-CC (583) GDMN (289) GDMU (290) GDMY (289) GDMY (full radius) (291)
- GDMY-F (291)
- GIA-K (long pocket) (299)
- GIF (long pocket) (298)
- GIF-E (W=8,10 full radius) (294)
- GIF-E (W=8,10) (292)
- GIFG-E (W=8) (581)
- GIPA/GIDA 8 (full radius) (302)
For holders, see pages: C#-GHAD-8 (625) C#-GHAPR/L-8 (626) GHAPR/L-8 (286) GHAR/L-8 (285) IM-GHAD-8 (634)
| CGFG 51-P8 Blades for Face Machining Carrying 8 mm Inserts | DAXN-DAXX CDX | OAL | H HF WB2 | OAH | Left-han | d shown | |||||
| Designation | CW | DAXN(1) | DAXX(2) | CDX | H | HF | OAL | OAH | WB2 | ||
| CGFG 51-180R/L-P8 | 8.00 | 180.0 | 240.0 | 70.00 | 52.6 | 45.0 | 200.00 | 60.0 | 27.5 | SR M4-2052 | HW 3.0 |
| CGFG 51-240R/L-P8 | 8.00 | 240.0 | 320.0 | 80.00 | 52.6 | 45.0 | 210.00 | 70.0 | 26.0 | SR M4-2052 | HW 3.0 |
| CGFG 51-320R/L-P8 | 8.00 | 320.0 | 440.0 | 90.00 | 52.6 | 45.0 | 220.00 | 80.0 | 24.5 | SR M4-2052 | HW 3.0 |
| CGFG 51-440R/L-P8 | 8.00 | 440.0 | 700.0 | 100.00 | 52.6 | 45.0 | 230.00 | 90.0 | 22.5 | SR M4-2052 | HW 3.0 |
| CGFG 51-700R/L-P8 | 8.00 | 700.0 | 1500.0 | 120.00 | 52.6 | 45.0 | 250.00 | 100.0 | 20.0 | SR M4-2052 | HW 3.0 |
- For user guide, see pages 604-613
(1) Minimum penetration diameter (2) Maximum penetration diameter
For inserts, see pages: GIMF (288) GIMM 8CC (583) GIMY (288) GIMY (full radius) (290) GIMY-F (291) GIPY (300)
For holders, see pages: SGTBK (617) SGTBU/SGTBN (616)
