ID5 TOOLS FOR ALUMINUM WHEELS 35° 7° S 52° 50° 70°MAXMAXMAX VCGT (PCD) RE 4.99 7° 91° 93° 72.5º 35° Rhombic Single Brazed L 31° Tip Corner Inserts for MAX 48°MAX Finishing Aluminum (PCD) D1 112° 117.5° 95º IC 35°MAX 95º 107.5º Dimensions Recommended Machining Data ap f Designation IC S RE L D1 (mm) (mm/rev) VCGT 160404D 9.52 4.76 0.40 16.60 4.40 • 0.10-3.00 0.05-0.30 VCGT 160408D 9.52 4.76 0.80 16.60 4.40 • 0.10-3.00 0.05-0.30 • For user guide and cutting speed recommendations, see pages 122-134, 236-254 For tools, see pages: A/S-SVLBCR/L (114) • A/S-SVLFCR/L; A-SVUCR/L (113) • A/S-SVQCR/L (113) • AVC-SVLCR/L-VH (98) • C#-SVJCR/L (66) • C#-SVJCR/L-JHP (66) • C#-SVVCN (69) • HSK A63WH-SVJCR/L (67) • SVJCR/L (453) • SVJCR/L-16-JHP (454) • SVVCN (454) • SVXCR/L (454) • AVC-SVLCR/L (96) GAMF GAMP SVHNR/L-AL-JHPScrew Lock Tools with Channels HF H 107.5º Bar Max for High Pressure Coolant LH Carrying 35° Rhombic Inserts WF B 107.5˚ LF Designation H B HF LF LH WF GAMP GAMF MIID(1) SVHNR/L 2525M-22-AL-JHP 25.0 25.0 25.0 146.34 36.3 30.03 7.0 6.0 VNGU 220630-R3N • For user guide, see pages 78-84 (1) Master insert identification For inserts, see pages: VNGU-R3N (210) Spare Parts Designation SVHNR/L 2525M-22-AL-JHP TVX 2230(a) SR 14-591/L-SN SW6-T-SH BLD T20/S7 HW 3.0 SR TC-4 CH-1.9D-JHP-A SET TVX 2212(b)* TVX 2216(c)* * Optional, should be ordered separately (a) For VNGU 220630-R3N insert (b) For VNGU 220612-R3N insert (c) For VNGU 220616-R3N insert LHGAMF GAMP 70°MAX SVVNN-AL-JHP 72.5º Bar Max Screw Lock Tools with Channels HF H for High Pressure Coolant Thread G1/8 Carrying 35° Rhombic Inserts WF B 72.5˚ LF Designation H HF B LF LH WF GAMP GAMF MIID(1) SVVNN 2525M-22-AL-JHP 25.0 25.0 25.0 150.00 41.0 12.50 0.0 -13.5 VNGU 220630-R3N (1) Master insert identification For inserts, see pages: VNGU-R3N (210) Spare Parts Designation SVVNN 2525M-22-AL-JHP TVX 2230(a) HW 3.0 BLD T20/S7 SW6-T-SH SR TC-4 SR 14-591/L-SN CH-1.9D-JHP-A SET TVX 2212(b)* TVX 2216(c)* * Optional, should be ordered separately (a) For VNGU 220630-R3N insert (b) For VNGU 220612-R3N insert (c) For VNGU 220616-R3N insert 457
