SNGU130604N SNGU130608N SNGU130608TN
.47 R.015 .26 .47 R.031 .26
SNGU130612N SNGU130616N SNGU1306ANTN
.532 R.047 .273 .47 R.062 .26
Part Number Application ades IN2505 IN2510 IN2530 IN2540 IN4015 IN4030 IN71N
SNGU130604N Positive Geometry - 0.015“ R SNGU130608N Positive Geometry - 0.031“ R SNGU130608TN Positive Geometry - 0.031" R w/.047" Wiper SNGU130612N Positive Geometry - 0.047" R SNGU130616N Positive Geometry - 0.062" R SNGU1306ANTN Positive Geometry - 0.031" Chamfer 45 deg. Wiper
HARDWARE
| Screw Retention Bolt | Coolant Bolt (Optional) | Driver Handle | Screw Driver Blade | ||||
| DJ6T-20R01 | SM40-100-R0 | SD-06-46 | SD-06-89 | DS-A00T | DS-T156B | ||
| DJ6T-25R01 | SM40-100-R0 | SD-06-46 | SD-06-89 | DS-A00T | DS-T156B | ||
| DJ5T-30R01 | SM40-100-R0 | SD-08-46 | SD-08-92 | DS-A00T | DS-T156B | ||
| DJ6T-30R01 | SM40-100-R0 | SD-08-46 | SD-08-92 | DS-A00T | DS-T156B | ||
| DJ5T-40R01 | SM40-100-R0 | SD-12-82 | SD-12-99 | DS-A00T | DS-T156B | ||
| DJ6T-40R01 | SM40-100-R0 | SD-12-82 | SD-12-99 | DS-A00T | DS-T156B | ||
| DJ6T-50R01 | SM40-100-R0 | SD-12-82 | SD-12-99 | DS-A00T | DS-T156B | ||
| DJ5T-60R01 | SM40-100-R0 | - | - | DS-A00T | DS-T156B | ||
| DJ6T-60R01 | SM40-100-R0 | - | - | DS-A00T | DS-T156B | ||
| DJ5T-80R01 | SM40-100-R0 | - | - | DS-A00T | DS-T156B | ||
| DJ6T-80R01 | SM40-100-R0 | - | - | DS-A00T | DS-T156B |
Insert screw torque for carbide: 30-35 in lbs. Use Torque wrench DT-35-02 with DS-T15B1 bit. Insert screw torque for SiNi: 28 in lbs. Use Torque wrench DT-28-01 with DS-T15B1 bit.
