MINI SA CHIPBREAKER GROUND POSITIVE ISO INSERTS FOR HIGH PRECISION TURNING • Peripherally ground geometry provides high accuracy • Low cutting forces due to an inclined, sharp cutting edge and wide groove geometry • Excellent chip control at low feed rates and depths of cut, due to an optimized chip-breaker design • Grade TT9020 suitable for Swiss sliding head turning centers • Grade TT5030 ideal for precision aerospace applications CCCCGGT TSASA - 7° POSITIVE, 80° RHOMBIC GROUND INSERTS WITH SA CHIPBREAKER ANSI ISO feed DOC Number Number (ipr) (inch) CCGT 21.50 SA CCGT 060201 SA .0008 - .006 .004 - .060 CCGT 21.50.5 SA CCGT 060202 SA .0008 - .006 .004 - .060 CCGT 21.51 SA CCGT 060204 SA .002 - .008 .004 - .095 CCGT 32.50 SA CCGT 09T301 SA .0008 - .006 .004 - .100 CCGT 32.50.5 SA CCGT 09T302 SA .0008 - .006 .004 - .100 CCGT 32.51 SA CCGT 09T304 SA .002 - .008 .008 - .100 =P =M =K =N =S =H 172 Grade TT5080 TT9020
