06 INSERTS FORMERLY R P HR
THES06 THES06_P THLS06
IC LE IC IC
LE LE
BS RE S BS RE S BS RE S
THLS06_HR
IC LE
BS RE S
| RE | BS | LE | IC | |||||
| Part Number | Application | Corner | Wiper | Cutting | Inscribed | S | ||
| Radius | Length | Edge | Circle | Thickness |
Length Diameter
| THES060404R | Multi-Purpose; Ground Periphery | 0.015 R | 0.051 | 0.270 | 0.272 | 0.157 | • | ||||||
| THES060408R | Multi-Purpose; Ground Periphery | 0.031 R | 0.035 | 0.270 | 0.272 | 0.157 | • | ||||||
| THES060404FR-P | Grd/Pol for Al | 0.015 R | 0.051 | 0.270 | 0.272 | 0.157 | • | ||||||
| THES060408FR-P | Grd/Pol for Al | 0.031 R | 0.035 | 0.270 | 0.272 | 0.157 | • | ||||||
| THLS060404R | Multi-Purpose | 0.015 R | 0.051 | 0.270 | 0.272 | 0.157 | • | • | • | • | |||
| THLS060408R | Multi-Purpose | 0.031 R | 0.035 | 0.270 | 0.272 | 0.157 | • | • | • | • • • | |||
| THLS060416R | Multi-Purpose | 0.062 R | 0.022 | 0.270 | 0.272 | 0.157 | • | • | |||||
| THLS060404R-HR | SS/Hi-Temp/Ti | 0.015 R | 0.051 | 0.270 | 0.272 | 0.157 | • | ||||||
| THLS060408R-HR | SS/Hi-Temp/Ti | 0.031 R | 0.035 | 0.270 | 0.272 | 0.157 | • | • | • |
06 HARDWARE FORMERLY
**OPTIONAL** **OPTIONAL** **OPTIONAL**
| Insert Screw | Screw Driver | Retention Bolt | Retention Bolt w/Coolant | Wrench | Torque Driver Handle | Preset Torque Bit | Torque Driver Bit | ||
| 1KJ1D-0601279R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-0702084R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-0701184R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-0701784R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-0703084R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-0801784R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1001780R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1001784R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1003780R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1003784R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1201780R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1201784R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1501780R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1501784R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-1502281R01 | SM25-065-R0 | DS-T08W | - | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-07015X6R01 | SM25-065-R0 | DS-T08W | - | - | 615MM | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-10015X7R01 | SM25-065-R0 | DS-T08W | - | - | 617MM | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-10015X7R02 | SM25-065-R0 | DS-T08W | - | - | 617MM | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-12017X8R02 | SM25-065-R0 | DS-T08W | - | - | 622MM | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| 1KJ1D-15017X8R01 | SM25-065-R0 | DS-T08W | - | - | 622MM | DS-A00-.25-S | DT-11-.25 | DS-TP08B | |
| KJ5D-15R01 SM25-065-R0 | DS-T08W | SD-04-46 | - | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | ||
| KJ5D-20R01 SM25-065-R0 | DS-T08W | SD-06-46 | SD-06-89 | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B | ||
| KJ6D-30R01 SM25-065-R0 | DS-T08W | SD-08-46 | SD-08-92 | - | DS-A00-.25-S | DT-11-.25 | DS-TP08B |
