FORMERLY
06


milling
SERIES 1KJ1D (WELDON SHANK)
90° END MILL (06MM INSERT)
Facing Shoulder Channeling Ramping Helical/Corkscrew Coolant

OAL
LPR
LUX

DC DCON

WEP .27APMX
90°KAPR WEP - See insert drawing for wiper options.

DC LUX LPR OAL ZEFF DCON RMPX
CSP
Part Number Cutting Usable Length Protruding Overall Effective Shank Ramp Angle
Coolant
Diameter Max. Length Length Teeth Diameter Max.
1KJ1D-0601279R01 0.625 1.22 1.25 3.25 1 0.625 Yes 4
1KJ1D-0702084R01 0.725 1.80 2.00 4.00 2 0.750 Yes 3.1
1KJ1D-0701184R01 0.750 1.05 1.25 3.25 2 0.750 Yes 3.1
1KJ1D-0701784R01 0.750 1.55 1.75 3.75 2 0.750 Yes 3.1
1KJ1D-0703084R01 0.750 2.80 3.00 5.00 2 0.750 Yes 3.1
1KJ1D-0801784R01 0.875 1.75 1.75 3.75 2 0.750 Yes 2.5
1KJ1D-1001780R01 1.000 1.55 1.75 4.00 3 1.000 Yes 2.1
1KJ1D-1001784R01 1.000 1.75 1.75 3.75 3 0.750 Yes 2.1
1KJ1D-1003780R01 1.000 3.38 3.75 6.00 3 1.000 Yes 2.1
1KJ1D-1003784R01 1.000 3.55 3.75 6.00 3 0.750 Yes 2.1
1KJ1D-1201780R01 1.250 1.75 1.75 4.00 5 1.000 Yes 1.5
1KJ1D-1201784R01 1.250 1.75 1.75 3.75 4 0.750 Yes 1.5
1KJ1D-1501780R01 1.500 1.75 1.75 4.00 6 1.000 Yes 1.3
1KJ1D-1501784R01 1.500 1.75 1.75 3.75 5 0.750 Yes 1.3
1KJ1D-1502281R01 1.500 2.25 2.25 4.50 6 1.250 Yes 1.3


49
