HF M
14 INSERTS
MNHU14_M MNHU14_PNR-M UNHU14_HF
IC
INSL INSL
LE LE
LE
W1 RE S BS RE S RE S
W1


RE BS LE INSL W1 NOI IH


IN2505
IN2530
IN2510
Grade
S
Part Number Application Corner Wiper Cutting Edge Insert Insert Number of Insert
Thickness
Radius Length Eff. Length Length Width Indexes Hand
MNHU140708R-M Multi-Purpose 0.031 - 0.540 0.551 0.551 0.362 4 Right • • •
MNHU140708PNR-M Multi-Purpose - Integrated Wiper 0.031 0.049 0.540 0.551 0.551 0.381 4 Right • •
REEQ LE INSL W1 NOI IH


IN2505
Grade
S
Part Number Application Program Radius Cutting Edge Insert Insert Number of Insert
Thickness
Equivalent Eff. Length Length Width Indexes Hand
UNHU140750R-HF Hi-Feed 0.196 0.118 0.551 0.551 0.267 4 Right •


14 HARDWARE
**OPTIONAL** **OPTIONAL** **OPTIONAL** **OPTIONAL** **OPTIONAL**
Screw Driver Handle Torx Driver Blade Retention Bolt Coolant Retention Bolt Wrench Torque Driver Handle Preset Torque Bit Torque Driver Bit
1TJ1J-1202281R01 SM50-127-10 DS-A00T DS-T206B - - - DS-A00-.25-T DT-44-.25 DS-T20B1
1TJ1J-1502281R01 SM50-127-10 DS-A00T DS-T206B - - - DS-A00-.25-T DT-44-.25 DS-T20B1
1TJ1J-12017X8R01 SM50-127-10 DS-A00T DS-T206B - - 622MM DS-A00-.25-T DT-44-.25 DS-T20B1
1TJ1J-15017X9R01 SM50-127-10 DS-A00T DS-T206B - - 630MM DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-20R01 SM50-127-10 DS-A00T DS-T206B SD-06-47 SD-06-A6 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-25R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ6J-25R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ6J-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-89 SD-12-99 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ6J-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-89 SD-12-99 - DS-A00-.25-T DT-44-.25 DS-T20B1


46
