GBP 57 ​ Extractor set with a sliding hammer in a plastic case Sturdy extractor (galvanised) with ergonomically shaped sliding hammer. Application: For extracting and pulling off parts with internal threads (taper pins or dowel pins) and ball bearings. The appropriate adapter or internal extractor is attached to the part to be extracted, which is then pulled off by firm strikes with the sliding hammer. Supplied with: 88 2000 – Pin extractor in a plastic case (275×230×80 mm) with 6 threaded inserts (M3 − M10), 3 adapters for internal extractors No. 882600. For M12 the slide bar is used without a threaded insert. Accepts threaded inserts to DIN 913. 88 2020 – Pin and ball bearing extractor in a plastic case (370×320×75 mm) with 10 threaded inserts (M3 - M18), 2 adapters for internal extractors and 5 internal extractors (⌀ 6 - 19 mm). 88 2000 88 2000 Pin extractor set eShop 83U Adapter for internal extractor M7×M12, M10×M12, 15-16G×M12 Hammer mass kg 0.9 Hammer travel mm 230 suitable for threads M3; M4; M5; M6; M8; M10; M12 88 2020 Pin and ball bearing extractor set eShop 83U Adapter for internal extractor M7×M12; M10×M12 Hammer mass kg 0.9 Hammer travel mm 150 Internal extractor for ⌀ mm 6 – 10; 8 – 12; 10 – 14; 12 – 16; 14 – 19 suitable for threads M3; M4; M5; M6; M8; M10; M12; M14; M16; M18 88 2020 ​ Sliding hammer Sturdy extractor jig (galvanised) with ergonomically shaped sliding hammer. Advantage: Very suitable for use on deep-seated components. Application: For extraction and pulling off ball bearings in combination with internal extractors (No. 88 2050_0,5 882600), using special adapters. Very versatile device for a wide variety of components. Energetic use of the sliding hammer pulls the components off. Supplied with: Extractor jig with appropriate adapters to suit various internal extractors. Note: Size 5 – Optional additional weights can be screwed on to increase the impact. 88 2050_1,7 88 2050_5 Hammer mass kg 0,5 1,7 5 88 2050 83U Sliding hammer eShop eShop eShop 15-16 G×G1/2, Adapter for internal extractor M7×M10 G3/4×G1/2 15-16 G×M10 Hammer travel mm 150 230 340 88 Total weight kg 0.7 2.5 6.5 ​ Extractor set in KUKKO L-BOXX® Composed of the most frequently used extractors for the most diverse extraction applications. Size 24A – Particularly suitable for automobile technicians. 88 2700_24B Type 24A 24B 24C 88 2700 83U Extractor set in KUKKO L-BOXX® eShop eShop eShop 2 KUKKO L-BOXX® 2 KUKKO L-BOXX® 3 KUKKO L-BOXX® Storage in size 136 size 136 size 136 Content: Size 1 Size 1; 2 Size 1; 2 1 each two-leg extractor No. 880100 1 each two-leg extractor No. 881000 Size 0 1 each pulling chuck 5−32 mm 1 each internal extractor No. 882600 Size 1−6 Size 1−8 size 1−7; 10 1 each support brace No. 882800 Size 1; 2 Size 1; 2 Size 1; 2; 4 934
