GBP 57 ​ Separator / extractor One side with separation claws for loosening flush fitted parts, the other side with normal extractor jaws. To free the bearing the separation claws are pressed between bearing and bearing seat by closing the clamp. The bearing is then fully removed by use of the spindle. Extractor jaws Application: For extracting ball races, pinions and so on, where access is difficult. For many jobs where normal extractors cannot be used due to lack of space. Optimum matching of the spindle to the shaft thanks to the 2-ended spindle tips. Clamp Type 1 2 3 88 1500 88 1500 83U Separator / extractor two legs eShop eShop eShop Jaw capacity mm 95 135 150 Separation claws Depth of reach up to mm 170 270 325 ​ “Powerplate” centre protector for use with extractors Advantage: Rotating centre permits higher tensile forces. Easy extraction even where the centring hole is too large or is absent. Adheres magnetically to the desired position. Application: Perfect protection of the centre when extracting ball bearings, sleeves, pulleys and gears. Extracting the components without Rotating centre = easy rotation. damage(protects the end of the shaft and the spindle) 88 1552_48 Magnet for securing to the end of the shaft. External ⌀ mm 18 28 38 48 “Powerplate” centre protector for shafts for 88 1552 83U eShop eShop eShop eShop extractors ​ Ball joint separator Sturdy body with pressure frame and strong spindle. Of high-quality tool steel. Simple and quick application: simply the push extractor frame between the ball joint and tighten the screw. The joint will separate easily. Application: For pressing out the ball studs when disassembling ball joints. Also as extractor for track rod ends. 88 1620_1 Type 1 0 88 1620 88 83U Ball joint separator eShop eShop for ball joints of nominal size mm 19 − 27 27 − 30 Lever travel capacity mm 50 Fork aperture mm 18 − 22 20 88 1620_0 ​ Hydraulic ram Steel body with hydraulic mechanism and automatic return. Easy handling: the ram is used between extractor spindle and shaft. Clamp ram with extractor spindle and tighten ram spindle (hydraulics come into effect). If the travel is insufficient, release the ram spindle and repeat the procedure. Application: For increasing the power of mechanical extractors from Size 3. Even tightly seized parts can easily be freed. 88 1800 Type 1 2 3 Hydraulic ram between shaft and 88 1800 83U Hydraulic ram eShop eShop eShop extractor spindle. Construction height mm 62 90 113 Ram cylinder ⌀ mm 14 23 39.5 Body ⌀ mm 37 50 80 Stroke mm 10 15 7 maximum permissible torque Nm 35 50 40 maximum permissible extraction force kN 100 150 300 933
