Ручные и измерительные инструменты Hoffmann Group 2026 - страница 926

GBP 57 ​ Pipe grip pliers “GRZRO” Quenched and tempered profile steel beam; quick adjustment; steplessly adjustable clamp jaw; clamping force adjustable (maximum 4000 N). With Vee jaws for holding round bodies of the same diameter. (Including plastic protective jaws, temperature-resistant to 200 °C.) Jaw capacity Throat ​ ​ mm mm 86 2150 Pipe grip pliers “GRZRO” 86 2150 eShop 110 65 83K with plastic protective jaws ​ Pole welding clamp “TP” with wing screw High quality malleable cast iron clamping arms with eyelet for electric welding cable on upper clamping arm. Strong spindle with ball-mounted captive pad. Clamp bright galvanised. Type 1 2 Pole welding clamp “TP” 86 2310 eShop eShop 83K with wing screw Slide beam cross section mm 25×6 30×8 Jaw capacity mm 150 Throat mm 80 60 for maximum current A 400 600 86 2310 ​ Clamping element for welding table 86 2350 Size 28/160 – Applicable only in conjunction with No. 377165. 86 2352 – Lever handle with locking mechanism for proportionate and vibration-proof clamping. Advantage: ■ Can be incorporated in to the welding table without using tools. ■ Wide variety of uses, and steplessly adjustable. ■ Convenient, secure, pin-point individual clamping. NEW NEW NEW NEW NEW 86 Type 86 2350_28/160 86 2350_16/100 16/100 28/120 86 2350_16/150 28/140 16/150 86 2351_16/100 28/160 86 2352_16/100 28/175 Clamping element for welding table 86 2350 eShop eShop eShop eShop eShop eShop 83P 2-component handle Clamping element for welding table 86 2351 (eShop) (eShop) – eShop – eShop 83P Tommy bar Clamping element for welding table 86 2352 eShop (eShop) (eShop) eShop – eShop 83P Lever handle Hole ⌀ mm 16 28 28 16 28 28 Version rigid rigid rigid variable can be swivelled variable Clamping height max. mm 200 300 300 200 – 300 Throat mm 100 120 140 30–150 0–160 40–175 Clamping elements for welding tables For quick-action table clamps and adjustable clamps for welding tables see Vol. 1 from No. 37 7065. 377065_BS 377065_GRS 926
