GBP 57 ​ C-clamp “SC” C-shape, forged steel, tempered. Strong spindle with trapezoidal thread and movable special jaw anvil. Application: Maximum clamping pressure up to 22,000 N. Jaw capacity mm 40 60 80 100 120 150 200 86 1550 C-clamp “SC” eShop eShop eShop eShop eShop eShop eShop 83K Throat mm 40 55 65 75 85 95 105 86 1550 ​ Variable high-performance clamp “SLV” Variable screw clamp – new flexibility with large spans up to 2 m! Beam of drawn profile steel, galvanised. End stops at each end can be removed without using tools. Slide jaw made of heat treatable steel, drop-forged. Wear-resistant smooth + running steel spindle with trapezoidal thread and movable (up to 35°) ping Clam ading special pressure pad. Spindle tempered and burnished with adjustable sp r e clamp handle. Application: Modular principle gives many different application possibilities in woodworking and metalworking. The moving jaws can be replaced with other ones or also further ones added. The switch from clamping to spreading requires no tools. Clamp can also be inserted through an opening in the workpiece. Central positioning on the workpiece prevents tipping. The movable special pressure pad permits clamping diagonal workpieces up to 35°. Maximum clamping pressure up to approx. 6500 N. Note: See spare parts list for No. 861756 (clamping 86 1750 handle), 861757 (wooden handle) or 861758 (lever handle) for spare sliding jaws. Jaw capacity mm 1000 1500 2000 Variable high-performance clamp “SLV” with 86 1750 eShop eShop eShop 83K special pressure pad and 2 clamp handles 35° 35° Cross section of the slide rail mm 27×13 Throat mm 120 Weight kg 4.78 5.97 7.15 ​ “STE” ceiling and assembly support Extremely stable structure thanks to high-tensile steel pipe and non-slip PVC contact surfaces. Single-handed operation thanks to 2-component plastic handle with pump mechanism. Pushbutton for quick extension and retraction of the telescopic rod. Holding force 86 adjustable by twisting the support on the grip. Up to maximum 160 kg (size 250) or 110 kg (size 300) load capacity when the telescopic rod is fully retracted. The contact surfaces can also be pivoted steplessly for use at angles -45° to 45°. 2-component plastic handle with quick adjustment button 9×7 cm size contact Application: For fixing plasterboard, wooden boards, panels, roof and pump mechanism. surfaces with a pivoting laths, metal strips, foils and luminaires at a height of angle of – 45° to 45°. up to 3.00 m. Can also be used without problems at angles due to the pivoted and non-slip PVC contact surfaces. When used at an angle, load capacity is limited to max. 40 kg. maximum length cm 250 300 86 1780 “STE” ceiling and assembly support eShop eShop 83K overall length cm 145 – 250 170 – 300 maximum load capacity kg 160 110 86 1780 Weight kg 3.1 3.5 924
