GBP 57 ​All-steel high-performance clamp Beam and fixed jaw made of bright steel section (special profile), tempered and electro-galvanised. Slide jaw made of steel, drop-forged, tempered, and electro-galvanised. Wear-resistant smooth-running steel spindle 35° 35° with trapezoidal thread. Long working life due to heat-resistant special pressure pad with sintered steel inlay, can tilt through 35°. Spindle tempered and burnished with adjustable clamp handle. Application: For heaviest duty clamping of workpieces in steel construction, blacksmith’s shops, HGV bodywork, machine tool manufacture etc. The movable special pressure pad permits clamping diagonal workpieces up to 35°. Maximum clamping pressure up to approx. 12000 N. ​86 1100 Jaw capacity mm 250 300 500 800 1000 1500 All-steel high-performance clamp “SGM” eShop 86 1100 eShop eShop eShop eShop (eShop) 83K with special pressure pad Quality features: strong Cross section of the slide rail mm 34×13 steel profile slide rails. Throat mm 140 Weight kg 2.5 2.9 3.4 4.4 4.9 6.5 Jaw capacity mm 250 300 500 800 1000 1500 All-steel high-performance clamp with 86 1120 eShop eShop eShop eShop eShop eShop 82C special pressure pad Quality features: strong Cross section of the slide rail mm 30×15 steel profile slide rails. Throat mm 140 ​86 1120 Weight kg 2.8 3 3.7 4.6 5.2 6.7 ​Heavy all-steel high-performance clamp Beam and fixed jaw made of bright steel section (special profile), tempered and electro-galvanised. Slide jaw made of steel, drop-forged, tempered, and electro-galvanised. Wear-resistant smooth-running steel spindle 35° 35° with trapezoidal thread. Long working life due to heat-resistant special pressure pad with sintered steel inlay. Spindle tempered and burnished with adjustable clamp handle. 86 1310 – Can tilt through 35°. 86 1320 – Can tilt through 30°. Application: For heaviest duty clamping of workpieces in steel construction, blacksmith’s shops, HGV bodywork, machine tool manufacture etc. The movable special pressure pad permits clamping diagonal workpieces. Maximum clamping pressure up to approx. 22000 N. 86 1310 Jaw capacity mm 300 400 500 600 800 1000 1500 86 1310 eShop eShop eShop eShop eShop eShop (eShop) 83K Heavy all-steel high-performance clamp with special pressure pad 86 1320 eShop eShop eShop eShop eShop eShop eShop 82C Quality feature:strong Vee profile steel slide rails. Cross section of the slide rail mm 40×20 Throat Weight (86 1310) mm kg 5.6 6.1 6.7 175 7.2 8.4 9.4 12.2 86 Weight (86 1320) kg 5.5 6 6.6 6.8 8.5 9.4 12 ​ Extra-heavy all-steel high-performance clamp “STBS” Beam and fixed jaw made of bright steel section (special profile), tempered and electro-galvanised. Slide jaw made of steel, drop-forged, tempered, and electro-galvanised. Wear-resistant smooth-running steel spindle with metric thread. Long working life due to heat-resistant special pressure pad with sintered steel inlay, can 35° 35° tilt through 35°. Spindle tempered and burnished with adjustable clamp handle. Application: For heaviest duty clamping of workpieces in steel construction, blacksmith’s shops, HGV bodywork, machine tool manufacture etc. The movable special pressure pad permits clamping diagonal workpieces up to 35°. Maximum clamping pressure up to approx. 35000 N. Jaw capacity mm 300 500 1000 Extra-heavy all-steel high-performance clamp “STBS” 86 1400 eShop eShop eShop 83K with special pressure pad Quality feature:strong Vee 86 1400​ Cross section of the slide rail mm 50×25 profile steel slide rails. Throat mm 200 Weight kg 10.5 12.2 17.3 923
