GBP 57 Punch ⌀ (hole ⌀) mm 28,3 30 32 32,5 35 37 40,5 45 83 4000 Round sheet metal punch without ball thrust bearing eShop eShop eShop eShop eShop eShop eShop eShop 86C 83 4100 Round sheet metal punch with ball thrust bearing eShop eShop eShop eShop eShop eShop eShop eShop 86C 83 4160 Gap sheet metal punch with ball thrust bearing eShop eShop eShop eShop eShop eShop eShop – 86C for metric threads to DIN EN 60423 – – – M32×1.5 – – M40×1.5 – for conduit threads to DIN 40430 PG21 – – – – PG29 – – Draw screw M10×1×55 M16×1.5×55 M16×1.5×70 hole ⌀ to be pre-drilled mm 11 11 11 17 17 17 17 17 Draw screw size mm 17 17 17 24 24 24 24 24 for material thickness (sheet metal St 37) mm 1.75 1.75 1.75 2.5 2.5 2.5 2.5 2.5 for stainless sheet steel depending on tensile strength up to mm 1.25 1.25 1.25 1.75 1.75 1.75 1.75 1.75 Punch ⌀ (hole ⌀) mm 47 50,5 54 60 63,5 70 75 80 83 4000 Round sheet metal punch without ball thrust bearing eShop eShop eShop eShop eShop eShop eShop eShop 86C 83 4100 Round sheet metal punch with ball thrust bearing eShop eShop eShop eShop eShop eShop eShop eShop 86C 83 4160 Gap sheet metal punch with ball thrust bearing – eShop – – eShop – – – 86C for metric threads to DIN EN 60423 – M50×1.5 – – M63×1.5 – – – for conduit threads to DIN 40430 PG36 – PG42 PG48 – – – – (83 4000, 83 4100) Draw screw M20×1.5×70 M20×1.5×80 M20×1.5×90 hole ⌀ to be pre-drilled mm 21 Draw screw size mm 30 for material thickness (sheet metal St 37) mm 3 for stainless sheet steel depending on tensile strength up to mm 2 Spare draw bolts Suitable for: 83 4040 – Round sheet metal punch No. 834000. 83 4060 – Round sheet metal punches No. 834100 and 834160. 83 4040 83 4060 Thread ⌀ / Length mm 6/30 8/35 10/45 10/55 16/55 16/70 20/70 20/80 20/90 Spare draw bolt for round sheet metal 83 4040 eShop eShop eShop eShop eShop eShop eShop eShop eShop 86C punches Spare ball bearing draw bolt for round 83 4060 – – – eShop eShop eShop eShop eShop eShop 86C sheet metal punches Screw dimensions M6×30 M8×1×35 M10×1×45 M10×1×55 M16×1.5×55 M16×1.5×70 M20×1.5×70 M20×1.5×80 M20×1.5×90 Width across flats mm Hex socket size 5 13 17 17 24 24 30 30 30 suitable for round sheet metal hole punches ⌀ mm 10 – 13 14 – 15.2 16 − 26 27 – 38 22.5 – 38 40 – 45 47 − 50.5 54 − 61 66 – 85 ​ Round sheet metal punch set to DIN EN 60423 for metric ⌀ ​ Supplied with: 1 each matrix punch and matrix (like round sheet metal punch No. 834000) for hole ⌀ 12.5 (M12×1.5); 16.5 (M16×1.5); 20.5 (M20×1.5); 25.5 (M25×1.5); 32.5 (M32×1.5); 40.5 (M40×1.5); 50.5 (M50×1.5); 63.5 (M63×1.5). 1 draw bolt (No. 834040 size 16/70). 4 ball thrust bearing draw bolts (No. 834060 size 10/55; 16/70; 20/90 and No. 834040 size 6/30 with ball thrust bearing). 1 step drill similar to No. 118320 (= ⌀ 7 - 21 mm). 83 1 sheet metal case size 335×230×55 mm. Round sheet metal punch set “Metric” ⌀ 12.5 − 63.5 mm in a sheet metal 83 4550 eShop 86C case 83 4550 “UNF” for metric ⌀ ​ Matrix punches and pressure screws with UNF fine thread. With ball thrust bearing draw bolts to reduce the friction. Compatible with all the main manufacturers of sheet metal punches with UNF threads. Three edged Supplied with: 1 each punch and matrix for hole ⌀ 16.2 (for M16); 20.4 (for M20 and PG13); 22.5 (for M22 sheet metal and PG16); 25.4 (for M25); 32.5 (for M32); 40.5 (for M40); 50.5 (for M50); 63.5 (for M63). punch ⌀ 16.2 − 25.4 with 3/8 inch UNF thread and ⌀ 32.5 − 63.5 with 3/4 inch UNF thread. 2 ball bearing draw bolts 3/8 inch − UNF, 40 mm. 1 ball bearing draw bolt 3/4 inch − UNF, 52 mm. 1 ball bearing draw bolt 3/4 inch − UNF, 65 mm. 1 HSS stepped drill (⌀ 6 − 21 mm). 1 robust plastic case, size 340×280×90 mm. Type 1 83 4555 Round sheet metal punch set “UNF” ⌀ 16.2 − 63.5 mm in a sheet metal case eShop 86C 83 4555 883
