GBP 57 ​ Shore hardness tester P1 Cal Shore hardness testers for determining hardness to Shore A or D to DIN ISO 7619-1 (supersedes DIN 53505) and ASTM D 2240. Sturdy, handy aluminium casing. 49 5002/5004 – High-contrast bright LED graphical display. Memory for 100 measurement values with date and time. USB interface for PC and charger. Application: 49 5002/5003 – Shore A: Soft rubber, elastomers, natural rubber products, cast resin, leather, neoprene rubber, polyester, plasticised PVC. 49 5004/5005 – Shore D: Hard rubber, hard plastics, Perspex, Formica, stiff thermoplastics, vinyl boards, polystyrene, pressure rollers. Optional extras: Test stand No. 495016. Test blocks for checking on request. 49 5002 49 5003 49 5002/5004 – Software for generating test certificates, statistics, and graphics available on request. Type A 49 49 5002 Digital hardness tester 49G eShop Shore A Analogue hardness tester 49 5003 49G eShop Shore A Type D Digital hardness tester 49 5004 49G eShop Shore D Analogue hardness tester 49 5005 49G eShop Shore D Test stand / supplementary weight ​ 49 5016 – Test stand for Shore hardness testers, specially for series testing. The test stand ensures that the hardness tester is exactly square to the surface of the test piece and that the correct gauging pressure is applied. Suitable for: 49 5016 – Shore hardness testers No. 495002 − 495005. 49 5018 – Shore hardness testers No. 495004; 495005. 49 5016 Test stand eShop 49G Throat mm 70 Test table ⌀ mm 170 Height mm 400 Supplementary weight 49 5018 (eShop) 49G 49 5016 for Shore D i Cal Digital rebound hardness tester dynaROCK III Sturdy casing made of powder-coated aluminium. Evaluation to DIN 50156 and ASTM A956 in Rockwell HRC and HRB, Vickers HV, Brinell HB, and the tensile strength of steel. The device can be used in any orientation (horizontal, facing upwards, facing downwards...). Internal memory for >1,000,000 measurement values, USB port for data transmission to a USB stick. User interface language: German, English. Accuracy: ±4 HL (0.5 % at 800 HL). Supplied with: Impact tool type D, hardness comparison block, USB data cable, cleaning brush, transport case, charger, and manufacturer’s certificate. Optional extras: Alignment rings for curved surfaces, test blocks with DAkkS certificate and impact tools types DC, DL, D+15, C and G on request. Spare part: Connecting cable to impact measuring tool 495023. Materials and hardness values (HLD 200 − 900) Material HRC HRB HB HV Steel and cast steel 20 – 68 60 – 100 80 – 650 80 – 940 Tool steel 20 – 68 – – 80 –940 Stainless steel 20 – 62 46 – 100 80 – 650 80 – 800 Cast iron – – 90 – 380 – Die-cast aluminium alloys – – 20 – 160 – Brass – – 40 – 170 – Bronze – – 60 – 290 – Copper – – 45 – 315 – ​ 1 49 5024 49G Digital rebound hardness tester eShop Minimum weight of test piece kg 2.5 Length mm 154 Width mm 84 Height mm 23 Weight g 430 282
