GBP 57 ​ Surface roughness measuring instrument SJ-220 and SJ-310 with skid system Digimatic Q1 Q2 RS232C Cal Cal Transportable cordless rail system for determining surface roughness. Gauge force 0.75 mN to DIN/ISO. Separate feed unit for measurements in very small spaces and for attachment to stands. Phase correction Gauss filter to DIN EN ISO 16610-21 (supersedes DIN EN ISO 11562). Automatic protection of the probe during transport. Auto-calibration function and integral memory for measurement conditions. 49 9205 – ■ High-resolution 2.8-inch touchscreen with user-friendly menu guidance. Feed unit can be operated as part of the main unit or separately. Measured data and measurement conditions can be archived to micro-SD memory card. 49 9205 ■ All recognised parameters to DIN EN ISO, VDA, JIS, ANSI, and freely selectable conditions. ■ Contains, among other things, the new roughness standard DIN EN ISO 21920. ■ Supports 25 languages. Feed unit in the device 49 9207 – ■ Very easy intuitive menu-guided controls with clear presentation of measured results and profiles on a 5.7 inch colour display. ■ Statistics function and colour-coded tolerance evaluation. ■ Large number of internationally recognised parameters to DIN EN ISO, VDA, JIS, ANSI, and MOTIF, and 16 integral languages. ■ Two different calculations can be performed based on just a single measurement. ■ Measurements where access is difficult or overhead can be performed using the separate feed unit. 49 ■ Automatic calibration function / mean value calibration can be performed with up to 12 multiple measurements. 49 9205 ■ Saving of up to 10 measurement conditions. ■ Quick output and documentation of measurement results, graphics and measurement conditions on the integral printer. Feed unit removed ■ Individual password protection. ■ Easy archiving of measured data on an SD memory card. Supplied with: Feed unit with contact point, mains adapter, calibration standard, and carrying case. 49 9207 – Includes 5 rolls thermal paper No. 499050, 1 pair of support legs No. 499220 size FUSS, rail for flat and cylindrical workpieces No. 499220 size Z-KUFE, mains adapter and user manual as USB stick. Optional extras: Transmitter and probe for small bores (from 2.5 mm) No. 499210, rail for flat and cylindrical components No. 499220 size Z-KUFE, support legs (2 pieces) No. 499220 size FUSS, adapter for clamping in height gauge No. 499220 size H-ADAPT, granite measurement stand No. 499415, printer No. 498702. 49 9205 Size SJ220 – Data cable No. 497081. 49 9207 Size SJ310 – Data cable No. 498430. Note: Free-of-charge analysis software, further adapters, and probes available on request. Application example Type SJ220 SJ310 49 9205 44D 44D eShop – Surface roughness measuring instrument 49 9207 – eShop maximum measuring range µm 360 graphic representation Measurement profile, BAC curve, ADC curve Roughness standards DIN EN ISO, VDA, ANSI, JIS, MOTIF Measurement travel for longitudinal sensing mm 17.5 16 Cut-off (λc) mm 0.08; 0.25; 0.8; 2.5; 8 Scanning speed mm/s 0.25; 0.5; 0.75 0.25; 0.5; 0.75; 1.0; ​ 49 9207 Accessories for surface roughness measuring instruments SJ-210, SJ-220, SJ-310, SJ-201 and SJ-301 ​ Suitable for: Roughness measuring instruments No. 499205 size SJ210 as well as SJ220 and No. 499207 size SJ310 as well as SJ201 and SJ301. Application: Size 2,5 – For small holes. Size 6/60 – Standard probe for SJ-210/220/310. 49 9210 49 9220 Size 6/90 – Standard probe for SJ-201/301. Type 2,5 6/60 6/90 49 9210 44D Sensor / probe head eShop eShop eShop Point angle degrees 90 60 90 Tip radius µm 5 2 2 _Z-KUFE minimum bore ⌀ mm 2.8 6.5 6.5 49 9220_FUSS Application: Size FUSS – Support legs (pair) for variable height adjustment of the probe. Size Z-KUFE – Rail for cylindrical components (also applicable for flat parts). Size H-ADAPT – Adaptor for clamping in height gauge No. 445152 For work where the feed unit cannot be placed on the component. Size EXT – Extension 50 mm for SJ-210 / SJ-310 series _H-ADAPT Type FUSS Z-KUFE H-ADAPT EXT 49 9205 49 9220 44D Optional extras eShop eShop eShop (eShop) 49 9207 279
