GBP 57 ​ Software options for MM1 Size DXF – Loading complex DXF files and overlaying them with the live image. The DXF coordinate system can be brought into conformity with that of the workpiece (congruence) or it can remain independent of the workpiece (for matching the workpiece to a DXF geometry). Definition of tolerance bands. Active change of colour when the tolerance band is exceeded. Exporting measured elements in DXF format. Definition and overlaying of cross-hairs. Size PROFIL – For the best possible matching of relative measurement points within a specified tolerance band (DXF option required). Several profiles with different tolerance ranges can be integrated into a single measurement procedure. Solely the component zero point must match that of the DXF file, following which the device (under CNC control), then automatically follows the contour. 49 1913_DXF Advantage: Size PROFIL – ■ Automatic matching of the measurement point cloud within a DXF tolerance band. ■ Automatic contour tracking in accordance with the DXF file that was loaded. Note: Individual links to your statistics software available on request. Size PROFIL – The availability of a DXF option (pre-existing or ordered with the tracking unit) is required for the profiling option. 49 Type DXF PROFIL 49 1913_PROFIL 49 1913 Software option for MM1 – (eShop) 41P Test standard Base plate of anodised aluminium including setting ring ⌀ 10 mm DIN 2250 (without chamfer) and glass standard No. 491926 with 6 sized holes. M6 tapped hole for attaching the calibration sphere No. 491929 size 20. Setting ring and glass standard supplied with manufacturer’s test certificate. Application: For setting and checking optical and tactile measurement tools. Supplied with: Base plate, setting ring ⌀10 mm, glass standard No. 491926 size 50×20. Optional extras: Ceramic calibration sphere ⌀ 20 mm No. 491929 size 20 49 1928 Length×Width mm 120×70 49 1928 41M Test standard eShop Glass standard with 6 sized holes and manufacturer‘s test certificate. 49 1926 Length×Width mm 50×20 49 1926 41M Glass standard with test certificate eShop Ceramic calibration sphere 20 mm ⌀ with M6 threaded mounting pin, supplied with manufacturer’s test certificate. ⌀ mm 20 49 1929 41M Calibration sphere ceramic (eShop) 49 1929 ​ Precision vices Precision vice in hard chrome-plated (brass) or anodised (aluminium) version. Ideal for use with small parts, e.g. on microscopes and shadowgraphs or with surface roughness measuring tools. Angular accuracy 0.04 mm, exchangeable clamping jaws of hardened, stainless steel and plastic. Fixed jaws with Vees for cylindrical parts. The additional Vee on the fixed jaw and the clamping slots on the long sides increase the versatility. Note: Also available as Inox version (stainless) on request. 49 4480 Jaw width A mm 15 25 35 49 4480 Precision vice eShop eShop eShop 42L maximum clamping range b mm 14.5 24.5 34.5 Jaw height C mm 6 10 14 Overall length a mm 50 75 100 Overall width B mm 15 25 35 Overall height c mm 15 25 35 Material of vice hard chrome-plated brass Aluminium anodised Aluminium anodised 260
