GBP 57 ​ Swivel eye bolts, quality class 8 High-strength swivel eye bolts, can be rotated through 360°, painted red. Note: SF 5:1 = Safety Factor 5. SF 4:1 = Safety Factor 4. Thread ⌀ 08 6467 Lifting capacity Lifting capacity L x A B C D 08Y WLL SF 5:1 WLL SF 4:1 Swivel eye bolt SEB t t mm mm mm mm mm mm M8 eShop 0.4 0.5 14 20 30 34 60 57 M10 eShop 0.5 0.7 17 20 30 34 60 57 08 6467 M12 eShop 0.8 0.9 21 20 30 34 60 57 X M16 eShop 1.4 1.8 27 35 38 45 88 80 90° M20 eShop 2 2.7 30 35 38 45 88 80 C B M-6g M-h6 X A M24 eShop 3.2 3.8 36 35 38 45 88 80 M30 eShop 5.5 6.3 45 50 58 70 115 106 D L S ​ Eye bolts / nuts to EN 1677-1, high-strength, quality class 8 High-strength eye bolts / nuts, red paint finish. Note: Do not place a load on the eye bolt / nut at 90° to the screw thread axis! SF 4:1 = Safety Factor 4. 08 6472 Thread ⌀ 08 6472 08 6477 Lifting capacity A B C D E F Thread 08Y 08Y WLL SF 4:1 length Eye bolt Eye nut ​ ​ ​ ​ ​ ​ ​ 08 6472 08 6477 t mm mm mm mm mm mm mm M6 eShop eShop 0.4 25 45 25 10 10 45 13 M8 eShop eShop 0.8 25 45 25 10 10 45 13 M10 eShop eShop 1 25 45 25 10 10 45 17 M12 eShop eShop 1.6 35 63 35 14 14 62 21 B D M16 eShop eShop 4 35 63 35 14 14 62 27 M20 eShop eShop 6 50 90 50 20 20 90 30 M24 eShop eShop 8 50 90 50 20 20 90 36 A F M30 eShop eShop 12 60 108 65 24 24 109 45 E M36 (eShop) – 16 70 126 75 28 26 128 54 M42 (eShop) – 24 80 144 85 32 30 147 63 M48 (eShop) – 32 90 166 100 38 35 168 68 C ​ Shackle, quality class 8 Curved shackle with locking screw made from high-tensile steel, galvanised surface. Note: SF 6:1 = Safety Factor 6. Lifting capacity WLL 08 6482 A B C D E 08 6482 08Y SF 6:1 Shackle t mm mm mm mm mm 0,5 eShop 12 6 29 8 20 0,75 eShop 14 8 31 10 21 1 eShop 17 10 37 11 26 2 eShop 21 13 48 16 33 4,75 eShop 32 19 71 22 51 8,5 eShop 43 25 95 29 68 12 eShop 52 32 119 35 82 17 (eShop) 61 38 148 42 98 25 (eShop) 73 45 177 51 127 ​ Hoist ring, quality class 8 Screw-on, 360° rotating attachment point for lifting heavy loads, ball-bearing mounted, 100% crack detection tested, certified by the DGUV. Note: SF 4:1 = Safety Factor 4. 08 Thread ⌀ 08 6486 Lifting capacity A B C D E H 08 6486 08Y WLL SF 4:1 C A B Hoist ring H t mm mm mm mm mm mm E M16 eShop 1.12 30 13 46 38 50 105 SW M20 eShop 2 34 16 57 50 61 131 L M24 eShop 3.15 40 18 70 58 68 153 M30 eShop 5.3 45 22 65 75 80 165 D D 1186
