Ручные и измерительные инструменты Hoffmann Group 2026 - страница 1125

GBP 57 ​ Soldering stations Size PICOMK2 – Simple i-CON PICO operating concept, for entry-level users. Universal application. Very small footprint and smart functions, can be set using a micro-SD card. Size NANOMK2 – Anti-static i-CON NANO microprocessor-controlled soldering station with high soldering heat output from an efficient high-power heating element. Solder tips are available with 08 2301_NANOMK2 the ideal tip geometry for every soldering task. Size ICON1MK2 – Multifunctional high-performance soldering station, adjustable via microSD memory card. Intelligent power management for the connected tools. Intuitive one-touch operation and large multifunction display. The station meets ESD requirements. Temperature control with dynamic power management. Manufacturer‘s designation PICOMK2 NANOMK2 ICON1MK2 08 2301_PICOMK2 08 2301 Soldering station eShop eShop eShop 04K Warm-up time to 280 °C s 9 9 – Control range of soldering tip temperature °C 150 – 450 150 – 450 50 – 450 Weight of soldering iron without power cable g 30 30 – Soldering fumes extraction ​ 08 2301_ICON1MK2 High extraction power − efficient filter performance − quiet operation. Filter the process air in 3 steps: ■ Pre-filter for dust and larger particles. ■ Combination filter for micro-particles. ■ Activated carbon filter absorbs harmful gases. Visual and audible display for filter change. Identical filter for EASY ARM 1 and EASY ARM 2. Interface for connecting i-CON soldering stations. The system is fitted using a suitable bench holder. Accessories such as extraction arms and nozzles can be found in the online shop under No. 082306 − 082313. 08 2304 – Extraction power is set on the system at the touch of a button, individually for each extraction arm. Number of filters/arms 1 2 ​ 08 2303 Soldering fumes extraction 08 2303 eShop – 04K Easy Arm 1 ​ 08 2304 Soldering fumes extraction 08 2304 – eShop 04K Easy Arm 2 Accessories ​ 08 2365 – Solder wire with 3.5 % flux core containing none of the prohibited elements Pb, Cd, Cr6, Hg. Regulations effective since 01. 07. 2006 (melt temperature 217 ° C) Soldering wire ⌀ mm 1 1,5 08 2365 04C Lead-free soldering wire Sn96.5, Ag3.0, Cu0.5, roll of 250 g eShop eShop ​ 08 2365 Manufacturer‘s designation 32KD 82JD 152JD G072KN G132KN 832SDLF 832CDLF 832EDLF BDLF 08 2400 04C Soldering tip eShop eShop eShop eShop eShop eShop eShop eShop eShop Soldering tip width mm 3.1 4.8 5.3 2.4 2.4 0.8 2.2 3.2 1 082150; suitable for 082100 30 082100 80 082100 150 082250 75 082250 130 082300; 082200 082300; 082200 082300; 082200 082200; 082300 08 Manufacturer‘s designation PDLF01 CDLF12 CDLF16 CDLF24 CDLF32 PDLF08 PDLF10 CDLF24A CDLF46A 08 2402 Soldering tip eShop eShop eShop eShop eShop eShop eShop eShop eShop 04K Soldering tip width mm 0.1 1.2 1.6 2.4 3.2 0.8 1 2.4 4.6 suitable for 082301 1125
