GBP 57 ​ Universal thread repair tool Universal thread repair tool for external threads. ■ Quick attachment using the adjustment screw. ■ Blade automatically adjusts to any thread lead. _4–13 ■ For cutting right-hand and left-hand threads to length (take into account the direction of rota- tion!). ■ Suitable for all types of thread (60° flank angle). for thread ⌀ mm 4-13 16-38 08 2855 04D Universal thread repair tool eShop eShop _16–38 ​ Screw / nut extractor for right-hand threads Made of tough chrome molybdenum steel. The sharp edges of the flutes bite into the jammed or broken screw / nut and bolt and allow it to be unscrewed. For use in combination with a ratchet, T-handle etc. Also suitable for round profiles or hexagon socket head screws. 08 2890 suitable for size across flats mm 8 10 13 15 16 17 19 22 24 08 2890 04D Screw / nut extractor eShop eShop eShop eShop eShop eShop eShop eShop eShop ⌀ drive output end mm 11.5 14.8 18.5 20.7 22.2 23.5 26 29.5 32 Length mm 32 32 32 32 32 42 42 42 42 Square drive in 3/8 3/8 3/8 3/8 3/8 1/2 1/2 1/2 1/2 suitable for screws M5 M6 M8 M10 M10 M10 M12 M14 M16 Screw / nut extractor set ​ Set contents 5 Screw / nut extractor set 08 2892 04D eShop 5 pieces Content: Size 10; 13; 17; 19; 24 5 screw extractors No. 082890 08 2892 ​Screw extractor Made of chrome vanadium steel. The sharp edges of the flutes dig into the drilled screw and allow it to be unscrewed. With square drive for use with tap wrench etc. Application: 08 2861 08 2861 – Suitable for both left-hand and right-hand threads. Suitable for hardened steel. 08 2862 – Suitable for aluminium, brass, stainless steel. 08 2865 – For extraction of broken-off screws with right-hand thread. 08 2862 08 2862/2864 – For extraction of broken off screws with right-hand thread (pre-drill the hole ⌀ as listed in the table; turn the screw extractor anti-clockwise). Note: 08 2861–2864 – UNC and UNF threads available on request. ​ 08 2864 ​ 08 2865 Type 1 2 3 4 5 6 Screw extractor 08 2861 04D eShop eShop eShop eShop eShop – double-edged, with tip Screw extractor 08 2862 04D eShop eShop eShop eShop eShop eShop with coarse flutes Screw extractor 08 2864 04D eShop ■ eShop ■ eShop ■ eShop ■ eShop eShop “Hi Trac” Screw extractor 08 2865 eShop eShop eShop eShop eShop eShop 01A 08 Pre-drill ⌀ (08 2861) Pre-drill ⌀ (08 2862) with fine flutes mm mm 3.2 2 4.8 3 6.4 5 9.5 6.4 11.1 8 – 12 Pre-drill ⌀ (08 2864) mm 1.8 3.2 4.5 6.5 8.5 12 suitable for screws/bolts (08 2861) M5 − M6 M8 − M10 M10 − M12 M12 − M16 M16 − M20 – suitable for screws/bolts (08 2862) M3 − M4 M5 − M7 M8 M10 − M12 M16 M18 − M22 suitable for screws/bolts (08 2864) M4 M5 − M7 M8 − M11 M12 − M14 M16 − M20 M20 − M24 suitable for screws/bolts (08 2865) M4 M6 − M8 M8 − M10 M12 − M14 M14 − M18 M18 − M24 suitable for (08 2861, 08 2864, 08 2865) hardened steel suitable for (08 2862) Aluminium; Brass; INOX suitable for pipe spigots (couplings) (08 2862, 08 2864, 08 2865) in – – – – 1/4 3/8 1126
