Enclosed hose reel
Automatic hose reel in plastic housing. PU flexible hose for compressed air with anti-kink protection. Integral hose guide. Pivoted bracket for wall mounting.
usable hose length m 15
08 0066 Automatic hose reel eShop
| Body width | mm | 465 |
| Body depth | mm | 220 |
| Body height | mm | 400 |
| Connection outlet | in | 3/8 |
| Connection inlet | in | 3/8 |
| maximum operating pressure | bar | 20 |
| usable hose length | m | 15 |
08 0066_15
Hose internal ⌀ mm 10
Open hose reel
Hose reels with automatic pull-out and roll-up mechanism guided by long life steel springs with multiple stop points per revolution. Size 15SCS; 20SCS – With patented SCS controlled automatic roll-up mechanism for avoidance of damage and injuries. 08 0074 – Open hose roll-up reel with aluminium cast body, galvanised pivoting run-out Size 15SCS and guide, and robust nylon-reinforced PVC hose. 20SCS with 08 0076 – Open hose reel in painted, partially galvanised sheet steel designwith variable damped automatic run-out guide and robust rubber hose. roll-up mechanism.
Application: For increased ergonomics by relieving cable tension, and for ensuring tidiness and for avoiding the risk of accidents and injuries due to hoses lying on the ground. 08 0074 – Suitable for air. 08 0074 08 0076 – Suitable for air, water, oil, diesel.
Type 20 20SCS 15 15SCS
08 0074 Hose reel
eShop eShop – –
cast aluminum reel 08 0076 Hose reel
– – eShop eShop
sheet metal reel
| Body width | mm | 380 | 380 | 470 | 470 |
| Body depth | mm | 155 | 155 | 180 | 08 0076 180 |
| Body height | mm | 375 | 375 | 494 | 494 |
| Connection outlet | in | 3/8 | 3/8 | 1/2 | 1/2 |
| Connection inlet | in | 3/8 | 3/8 | 1/2 | 1/2 |
| maximum operating pressure | bar | 20 | 20 | 50 | 50 |
| usable hose length | m | 20 | 20 | 15 | 15 |
Mounting plates for attaching hose reels to the wall with 120° pivoting range.
08 0084 Pivoting mounting plate for No. 080074 eShop
08 0084
08 0086 Pivoting mounting plate for No. 080076 (eShop)
All-plastic generation 7 “Coworker” compressed-air hose drum with a drum diameter of 250 mm. The ergonomically designed carrying handle and the rotation stop switch for securing the drum body are special features of this cable drum.
usable hose length m 20
08 0061 Compressed air hose reel 1/4 inch eShop
| maximum operating pressure | bar | 12 | |
| usable hose length | m | 20 | |
| Hose internal ⌀ | mm | 9 | 08 0061 |
Drip-free couplings for liquids 08
For the field of fluid supply, we offer high-quality, drip and leakage-free couplings and hose sets tailored to each application area on request. Colour and mechanical Designed for all types of liquid transfer coding prevents them from e.g. cold or hot water, dielectric liquids, being mixed up accidentally. glycols and mineral oil and synthetic-based heat transfer oils.
