​ Pneumatic accessories
Hose support ​
Aluminium hose support, unpainted. For easy wall -mounting.
Suitable for: Maximum 50 m hose turns at an internal ⌀ of:
Size 9 – 9 mm
Size 13 – 13 mm

08 0027
Type 9 13
08 0027
08A


Hose support eShop eShop Fig. Hose support
No. 955760_225
Hose clips ​
08 0052 – Hose clip of chromium steel with galvanised 7AF hexagon bolt.
Belt width 9 mm.
08 0054 – 2-lug hose clips of bright chromium galvanised steel.
Note: For hose clip pliers see No. 719985 size 220.
08 0052 08 0054
Clamping range hose external ⌀ mm 5-7 7-9 9-11 11-13 13-15 14-17 17-20 20-23 10-16 12-20
Hose clip set
08 0052
08A


– – – – – – – – eShop eShop
10 pieces
2-lug hose clip set
08 0054
08A


eShop eShop eShop eShop eShop eShop eShop eShop – –
10 pieces

​Coiled hoses
Very light, flexible, and abrasion-resistant PU spiral hose with good spring retention.
Temperature-resistant from -20 / 60 °C.
Supplied with:
08 0240/ 0241 – Safety steel coupling No. 080285 and steel coupling adaptor No. 080290 included.
08 0238/0239 – Includes GARANT steel safety quick-change coupling and steel coupling adaptor.

usable hose length m 3 5
PU coiled hose 1/4 inch
08 0238 with steel safety coupling eShop eShop 08 0238
01A


⌀ 8 × 12 mm
PU coiled hose 1/2 inch
08 0239 with steel safety coupling eShop eShop
01A


⌀ 11 × 16 mm
maximum operating pressure bar 10
usable hose length m 2 4 6 8
PU coiled hose 1/4 inch
08 0240
08A


with eSafe steel safety coupling eShop eShop eShop eShop
⌀ 8 × 12 mm
PU coiled hose 1/2 inch
08 0241
08A


with eSafe steel safety coupling – eShop eShop eShop
⌀ 11 × 16 mm
maximum operating pressure bar 10
Flexible nylon hose. Temperature-resistant from -60 / +60°C. 08 0240
Supplied with: Supplied with 1 piece each of brass quick-release coupling and coupling adaptor.
usable hose length m 2,5 5 7,5
08 0057
02A


Coiled 1/4 inch nylon hose, with coupling eShop eShop eShop
08 0058
02A


Coiled 3/8 inch nylon hose, with coupling – eShop –
maximum operating pressure bar 10
Hose external ⌀ (08 0057) mm 8
Hose external ⌀ (08 0058) mm – 12 –
Hose internal ⌀ (08 0057) mm 6
Hose internal ⌀ (08 0058) mm – 9 –
08 0057
Hose is polyurethane, therefore extremely resilient, extremely high retracting force, 08 0058
low pressure drop and low permanent deformation.
Temperature-resistant from -40/ + 60°C.
Supplied with: Rotating assembly and kink protection spring.
usable hose length
PU coiled hose 1/4 inch
m 3 7,5 08
08 0101
08A


with rotating screw attachment eShop eShop
and anti-kink protection
PU coiled hose 3/8 inch
08 0106
08A


with rotating screw attachment eShop eShop
and anti-kink protection
Hose external ⌀ (08 0101) mm 8
08 0101
Hose external ⌀ (08 0106) mm 12
08 0106
Hose internal ⌀ (08 0101) mm 5
Hose internal ⌀ (08 0106) mm 8
