​Construction site & workshop compressor NEW
07 9842 Size 180/5W – Compact and portable reciprocating compressor. Ideal for stapling and nailing.
Size 700/90D – Powerful and robust compressor for demanding applications. Extremely high performance
and long service life.
07 9844 – M18 FUEL™ cordless compressor. Conventional nailers and tackers can be operated with an
air pressure of 2.8 bar and an effective delivery quantity of 48 l/m. Sound pressure level of _180/5W
only 68 dB(A) for pleasant working conditions.
Size 250/24OF; 270/50OF – Silent compressor for general-purpose use.
Supplied with:
07 9844 Size M18FAC – Version without batteries and without charger. _250/240F
Note:
07 9844 – See No. 073833 M18HNRG12 for suitable battery starter set.
NEW

_270/500F


Type 180/5W 250/24OF 270/50OF 700/90D M18FAC
Construction site &
07 9842
03D


(eShop) (eShop) (eShop) (eShop) –
workshop compressor
07 9844 Cordless compressor – – – – (eShop)
03L


Power consumption kW 1.1 1.5 1.5 4 0.4
maximum pressure (air) bar 8 8 10 11 9.31
maximum suction rate l/min 160 200 250 650 126
maximum filling rate l/min 90 110 130 520 74 _700/90D
Pressure vessel volume l 5 24 50 90 7.6
Weight kg 16 27 37 119 14.4
Length mm 370 620 715 1188 500
Width mm 395 340 390 520 500
Height mm 286 580 650 1110 500
AC supply voltage V 230 230 230 380-415 –
Battery voltage V – – – – 18 _M18FAC

L
​ Service units
Service unit in modular series (“multifix” system), consisting of filter, pressure regulator and mist atomiser.
Control range 0.5- 10 bar, operating pressure maximum 16 bar, operating temperature maximum 60 °C.
08 0015 – 2-part service unit, assembled, with pressure regulator, oil atomiser and filter.
Advantage: The service unit can be configured individually, e. g. with several pressure regulators,
without oil atomiser (for oil-free tools) etc.
H
08 0015
08 0015 2-part service
Internal thread ⌀ in 1/4 3/8 1/2 unit, supplied
assembled
08 0011
08A 08A 08A 08A


Filter controller eShop eShop eShop
08 0012 / 08 0013 / 08 0014
Pressure regulator
08 0012 0.5 −10 bar eShop eShop eShop Individual modules can be
assembled into a three-part unit.
08 0013 Oil atomiser eShop eShop eShop
Filters
08 0014 5 µm eShop eShop eShop
Service unit
08 0015
08A


eShop eShop eShop
2-part assembled
Height (H) mm 190 196 248
Overall length (L) as 2-part service unit 93 93 136
(08 0015) mm
Overall length (L) as 3-part service unit 138 183 202
(08 0012, 08 0013, 08 0014) mm
Flow rate for 3-part service unit 1150 1150 3100
(08 0012, 08 0013, 08 0014) l/min 08 0011 08 0012 08 0013 08 0014
Application: Oil atomiser for reliable supply to oil-lubricated pneumatic tools,
even in long piping systems. NEW
Internal thread ⌀
08 0021
in G1/4
07
08A


Oil atomiser attachment 1/4 Zoll eShop
Digital pressure gauge with backlighting in a sturdy plastic case for monitoring and measurement of pressures
08 0021
in dry oil-free compressed air and non-toxic non-aggressive gases.
Supplied with: Button cell CR2032.
Display range bar 0-10
08 0031
08A


Digital pressure gauge eShop
08 0031
Connection thread in 1/4 inch external thread
