GBP 57 For cylindrical external or flat faces (recommended from ⌀ 50 mm) ​ Advantage: Consistent results due to continuous measurement of the rolling force. Note: Tool tray for the respective machining surface depends on the type of turret (star/disc). LA LA 29 1510_VDI40 29 1515_VDI40 f f Shank mounting type S25 S32 VDI40 VDI50 PSC63 PSC80 29 1510 (eShop) (eShop) (eShop) (eShop) – – 29F 29F Smooth rolling tool EG14 universal 29 1515 – – (eShop) (eShop) (eShop) (eShop) LA (29 1510) mm 132 132 131 131 – – LA (29 1515) mm – – 158.1 158.1 196 196 f (29 1510) mm 103.6 103.6 71.3 71.3 – – f (29 1515) mm – – 44 44 44 44 maximum rolling force kN 8 Roll ⌀ mm 14 Shank square mm 25×25 32×32 – – – – Suitable for: from 50 mm ⌀ range (recommended) For external surfaces with transition radii ​ Advantage: Consistent results due to continuous measurement of the rolling force. LA Recommendation: For external surfaces with subsequent radius up to plane surface. Note: Roller radius = 2.5 mm. Machinable workpiece radii from 4 mm to 12 mm. 29 1520_S25 f Shank mounting type S25 S32 VDI40 VDI50 PSC63 PSC80 Smooth rolling tool EG45-40M 29 1520 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 29F universal LA mm 130 130 129 129 151 166.3 f mm 101.1 101.1 69 69 69 69 maximum rolling force kN 4 Roll ⌀ mm 40 Shank square mm 25×25 32×32 – – – – Suitable for: from 35 mm ⌀ range (recommended) For external surfaces and holes ​ High flexibility due to external and internal use. Independent of diameter (within the recommended range) for internal machining. LA Advantage: Consistent results due to continuous measurement of the rolling force. Application: For external ⌀ from 10 mm and internal ⌀ from 32 mm. 29 1530_VDI30 Supplied with: Two spare rolls built in the cage. LN 29 f Shank mounting type S20 S25 VDI20 VDI25 VDI30 VDI40 Smooth rolling tool EGI5-32AI 29 1530 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 29F universal LA mm 154 154 168 168 168 168 f mm 73.2 82.2 58 58 58 58 LN mm 100 maximum rolling force kN 3 Roll ⌀ mm 5 Shank square mm 20×20 25×25 – – – – Suitable for: 10 mm – 100 mm ⌀ range outside (recommended) ⌀ range inside (recommended) 32 mm – 150 mm 912
