GBP 57 DOVEIQGRIP toolholder OAL G1/8” H H HBL HBH WB CW B WF CDX 27 4140_25 Shank size / groove width w 27 4140 27 4141 HBH HBL CDX WF OAL WB 26D 26D DOVEIQGRIP THD toolholder mm right-hand left-hand mm mm mm mm mm mm 25/10 (eShop) (eShop) 8 30 20 20.4 170 9.2 25/12 (eShop) (eShop) 8 30 20 19.5 170 11 25/14 (eShop) (eShop) 8 30 20 18.5 170 13 32/16 (eShop) (eShop) 8 48 40 24.6 170 14.8 40/16 (eShop) (eShop) – – 50 32.6 180 14.8 ​ DOVEIQGRIP inserts Y chip breaker for general groove machining. Positive chip former. Soft cut. Application: For grooving for high metal removal rates. S CW 60.5° RE INSL Groove width w 27 4148 27 4149 Corner radius R CWTOL fg RETOL INSL 27 26H 26H DOVEIQGRIP TIGER-IQ insert mm IC808 IC830 mm mm mm/rev. mm mm 10 eShop eShop 10 0.8 0.08 0.2 – 0.35 0.05 13.3 12 eShop eShop 10 1.2 0.08 0.2 – 0.4 0.05 14 14 eShop eShop 10 1.5 0.08 0.22 – 0.45 0.05 161 16 eShop eShop 10 1.5 0.08 0.22 – 0.5 0.05 20 UNI UNI Chip breaker ZC ZC ​ ​ ​ ​ ​ ​ vc main application m/min 80 – 180 80 – 180 ​ ​ ​ ​ ​ ​ 871
