GBP 57 LOGIQFGRIP tool blocks Suitable for: TANGFGRIP adapter No. 273610, 273611 and 273614. Application: For parting off and grooving. Note: Coolant transfer to tool block via G 1/8 inch hose coupling or directly via suitable ISCAR toolholders. 27 3600_25 L OAW CUTDIA H OAH B LB Shank size mm 16 20 25 27 3600 26D 26D 26D 26D 26D 26D right-hand (eShop) (eShop) (eShop) 27 3601 left-hand (eShop) (eShop) (eShop) 27 3602 LOGIQFGRIP tool block right-hand – (eShop) (eShop) 27 3603 left-hand – (eShop) (eShop) 27 3604 right-hand – – (eShop) 27 3605 left-hand – – (eShop) CUTDIA (27 3600, 27 3601) mm 42 CUTDIA (27 3602, 27 3603) mm – 52 52 CUTDIA (27 3604, 27 3605) mm – – 120 OAH (27 3600, 27 3601) mm 40 OAH (27 3602, 27 3603) mm – 50 50 OAH (27 3604, 27 3605) mm – – 95 LB (27 3600, 27 3601) mm 35 LB (27 3602, 27 3603) mm – 42 40 LB (27 3604, 27 3605) mm – – 73 ​ TANGFGRIP adapter 27 3610 – Without through-coolant feed. Suitable for: Tool blocks No. 273600 – 273605. Attention: Please order the assembly key No. 279955 separately. 27 OAH HF CUTDIA OAL CWN-CWX WB 27 3614_3,05 Groove width w mm 2 3,05 4 Suitable for: 27 3610 26D 26D 26D neutral eShop eShop – LOGIPFGRIP 27 3611 TANGFGRIP adapter neutral eShop eShop eShop LOGIPFGRIP 27 3614 neutral – eShop eShop LOGIPFGRIP CUTDIA (27 3610) mm 42 42 – ​ CUTDIA (27 3611) mm 52 ​ CUTDIA (27 3614) mm – 120 120 ​ 869
