GARANT Master Mute vibration-damping boring bar shanks

With modular interface, suitable for systems from other manufacturers (e.g. Iscar).

Supplied with: Reducing adaptor for coolant connection.

Note: Do not clamp on the area marked S! D = 1/2 shank ⌀ + H + cutting head centre-line

offset L . Usable length = overall length L minus clamping length (recommended = 3×D). min Use only with internal cooling3 (temperature resistance of up to max. 100°C).

Up to 15 × D

H L 3 S L 26 5076

Shank ⌀ /26 5076Number ofLVersionHSrecommendedAssembly bolt setConnection
overall lengthcoolant channelsclamping lengththread

L GARANT Master Mute boring bar shank vibration damping

mmmmmmmm
16/170eShop3170Steel–7448269026 1G1/4
16/204eShop3204Carbide-reinforced–8548269026 1G1/8
16/268(eShop)3268Carbide-reinforced–10248269026 1G1/8
20/200eShop3200Steel–8460269026 1G1/4
20/260eShop3260Carbide-reinforced–11960269026 1G1/4
20/340(eShop)3340Carbide-reinforced–11860269026 1G1/4
25/255eShop3255Steel–10775269026 4G1/4
25/330eShop3330Steel–12575269026 4G1/4
25/430(eShop)3430Carbide-reinforced–14575269026 4G1/4
32/320eShop3320Steel–12496269026 5G1/2
32/416eShop3416Steel–15196269026 5G1/2
32/544(eShop)3544Carbide-reinforced–17996269026 5G1/4
40/408eShop3408Steel–144120269026 3G1/2
40/528eShop3528Steel–196120269026 3G1/2
40/688(eShop)3688Carbide-reinforced–224120269026 3M36×1
50/518eShop1518Steel5187150269026 3G3/4
50/660eShop1660Steel5269150269026 3G3/4
50/861(eShop)1861Carbide-reinforced5269150269026 3G1/4
60/628eShop1628Steel10230180269026 3G3/4
60/808eShop1808Steel10309180269026 3G3/4
60/1040(eShop)11040Carbide-reinforced10333180269026 3G3/8

GARANT Master Mute exchangeable cutting heads

L3

For negative indexable inserts L

Suitable for: Vibration-damping boring bar shanks No. 265060 – 265076.

26 5100 26 5101 26

Shank ⌀ /Number ofsuitable⌀ DLLShimShim screwClampScrew for
insert sizecoolantindexable insertmin3clamping

channels claw GARANT Master Mute exchangeable cutting head DCLN

right-hand left-hand mm mm mm

40/12(eShop)(eShop)3CN.. 1204..502733269005 22269013 9259038 21259021 826 5100
Shank ⌀ /26 510226 5103Number ofsuitable⌀ DLLShimLeverLever screw
insert sizecoolantindexable insertmin3

GARANT Master Mute channels exchangeable cutting head PCLN

right-handleft-handmmmmmm
32/12eShop(eShop)3CN.. 1204..402726269005 13259015 18259018 19
40/12eShop(eShop)3CN.. 1204..503326269005 13259015 18259018 1826 5102
