3×D
A... SDUC 93° boring bars for indexable inserts DC..

27°
Boring bar stepped ​
Standard
L
L
L2
Ds
L
L 26 0342_0810/07
T
Shank ⌀ / in- 26 0342 26 0343 ⌀ Ds ISO code toolholder suitable indexable ⌀ Dmin L3 L2 T L4 L1 L Set of insert screws
21T


21T


sert size insert
Boring bar steel
mm right-hand left-hand mm ​ ​ mm mm mm mm mm mm mm ​
0408/04 eShop eShop 8 A0408F SDUCR/L04 DC.. 04T0.. 5.2 3 7.5 1.5 4 15 80 269028 26
0810/07 eShop eShop 10 A0810H SDUCR/L07 DC.. 0702.. 12.5 6.5 9 4.4 7 22.5 100 269028 7
1012/07 eShop eShop 12 A1012K SDUCR/L07 DC.. 0702.. 15.5 9 11 5.9 9 27.5 125 269028 7
1216/07 eShop eShop 16 A1216M SDUCR/L07 DC.. 0702.. 18 11 15 4.9 12 40.5 150 269028 7
Boring bar cylindrical ​
DIN
8024 Standard
L
L2
Ds
L
26 0342_25/11
Shank ⌀ / in- 26 0342 26 0343 ⌀ Ds ISO code toolholder suitable indexable ⌀ Dmin L3 L2 L Set of insert Shim Shim screw
21T


21T


sert size insert screws
Boring bar steel
mm right-hand left-hand mm ​ ​ mm mm mm mm ​ ​ ​
10/07 eShop ■ eShop 10 A10K SDUCR/L07 DC.. 0702.. 13.5 7 9 125 269028 7 – –
12/07 eShop ■ eShop 12 A12L SDUCR/L07 DC.. 0702.. 16 9 11 140 269028 7 – –
16/07 eShop ■ eShop 16 A16Q SDUCR/L07 DC.. 0702.. 20 11 14 180 269028 7 – –
20/11 eShop ■ eShop 20 A20R SDUCR/L11 DC.. 11T3.. 25 13 18 200 269028 8 – –
25/11 eShop ■ eShop 25 A25R SDUCR/L11 DC.. 11T3.. 32 17 24 200 269028 8 – –
32/11 eShop eShop 32 A32S SDUCR/L11 DC.. 11T3.. 40 22 31 250 269028 2 269005 3 269013 2
40/11 eShop eShop 40 A40T SDUCR/L11 DC.. 11T3.. 49 27 39 300 269028 2 269005 3 269013 2

3×D
A... SDXC 93° boring bars for indexable inserts DC..

DIN
26
L 8024 Standard
L1
L2

32° L3 T
26 0344
Shank ⌀ / in- 26 0344 26 0345 ISO code toolholder suitable indexable ⌀ Dmin L3 L2 T L1 L Set of insert screws
21T


21T


sert size insert
Boring bar, steel
mm right-hand left-hand ​ ​ mm mm mm mm mm mm ​
8/04 eShop eShop A08F SDXCR/L04 DC.. 04T0.. 9.2 5 7.5 3 15 80 269028 26
10/04 eShop eShop A10H SDXCR/L04 DC.. 04T0.. 12.5 7 9 5 22 100 269028 26
12/07 eShop eShop A12L SDXCR/L07 DC.. 0702.. 17 9 11 4.3 25 140 269028 7
16/07 eShop eShop A16Q SDXCR/L07 DC.. 0702.. 21 11 15 4.3 33 180 269028 7
20/11 eShop eShop A20R SDXCR/L11 DC.. 11T3.. 25 13 18 10 40 200 269028 8
25/11 eShop eShop A25R SDXCR/L11 DC.. 11T3.. 31.5 17 23 10 50 200 269028 8
