GBP
57

Carbide DIN
8024 Standard
8×D
E... SDUC 93° boring bar sets for indexable inserts DC..


L
L2
L Ds
27°
26 0324
26 0324 26 0325 ISO code toolholder suitable ⌀ Dmin L3 L2 L Set of insert screws
29W


29W


indexable insert
Boring bar set
carbide
right-hand left-hand ​ ​ mm mm mm mm ​
E10K SDUCR/L07; 12; 7; 9.6; 125;
eShop eShop DC.. 0702.. 269028 7
E12M SDUCR/L07 15 9 11.6 150

HSS
5×D Standard
AH... SDQC 107.5° boring bars for indexable inserts DC..
L
L L2
Ds
L
15° 26 0328
Shank ⌀ / insert 26 0328 26 0329 ISO code toolholder suitable ⌀ Dmin L3 L2 L1 L Set of insert screws
21T


21T


size indexable insert
Boring bar
HSS
mm right-hand left-hand ​ ​ mm mm mm mm mm ​
8/07 eShop eShop AH08K SDQCR/L07 DC.. 0702.. 12 8 7 20 125 269028 7
10/07 eShop eShop AH10K SDQCR/L07 DC.. 0702.. 13 8 9 20 125 269028 7
12/07 eShop eShop AH12M SDQCR/L07 DC.. 0702.. 16 9.5 11 20 150 269028 7
16/07 eShop eShop AH16Q SDQCR/L07 DC.. 0702.. 20 12 15 30 180 269028 7
20/11 eShop eShop AH20R SDQCR/L11 DC.. 11T3.. 25 14.5 18 40 200 269028 8
25/11 eShop eShop AH25R SDQCR/L11 DC.. 11T3.. 32 17 23 40 200 269028 8

HSS
5×D Standard
AH... SDUC 93° boring bars for indexable inserts DC..

26 27°
Boring bar stepped ​
L
L L2
Ds
L
L
T 26 0332_0810/07

Shank ⌀ / insert 26 0332 26 0333 ⌀ Ds ISO code toolholder suitable ⌀ Dmin L3 L2 T L4 L1 L Set of insert screws
21T


21T


size indexable insert
Boring bar
HSS
mm right-hand left-hand mm ​ ​ mm mm mm mm mm mm mm ​
0810/07 eShop eShop 10 AH0810H SDUCR/L07 DC.. 0702.. 12.5 7 9 5 8 22 100 269028 7
1012/07 eShop eShop 12 AH1012K SDUCR/L07 DC.. 0702.. 15.5 9 11 5 10 28 125 269028 7
1216/07 eShop eShop 16 AH1216M SDUCR/L07 DC.. 0702.. 19.5 11 15 5 12 36 150 269028 7
782
